Front Panel LED Description

Figure 1-4 and Table 1-1 provide color and description of the C2 Communications
Controller front panel LEDs.
1
2
Item# LED
Mute Status
1
(Red)
Line 1/Line 2 Status
2
(Red)
Page Active
3
(Red)
Door Bell Status (D1-D4)
4
(Red)
Relay Status (R1-R4)
5
( )
Red
Power Indicator
6
(Blue)
© ELAN Home Systems 2009 • All rights reserved.
3
4
[ ]
[ ]
Figure 1-4: C2 Front Panel LEDs
Indication
Solid ON
Flashing
Slow Wink
Solid ON
Solid ON
Solid ON
Solid ON
Solid ON
Table 1-2: C2 Front Panel LED's
5
C2
INSTALLATION MANUAL
6
OPEN
ACCESS
DOOR
Status
During music mute
function (#,6). Default
is OFF.
Incoming call
Call On-Hold
Phone Off-Hook.
Default is OFF
During page function
(#,7). Default is OFF
During door chime
duration. Default is
OFF
During relay activation,
remains active
until button is
released. (#,1,1 for
Relay 1, #,1,2 for
Relay 2 etc.) Default is
OFF.
Indicates Power
Switch is set to the ON
position. Default is
ON.
Page 19
