C2 to S86A Multi-Chassis Connections

The S86A utilizes outputs for Page Audio and Page Trigger in order to facilitate multiple chassis.
Use a mono RCA interconnect cable for Page Audio, and 3.5mm mono interconnects for Page
Triggers as shown in the diagram.
Multiple S86A Chassis Connections
Page/Door Chime/MOH
3.5mm Mono
Interconnect Cable
SUM Trigger Output
S86A responds to Page, all doorbells and
Trigger Inputs.
SUM PG
TRIGGERS
1 2
+ - + - + -
DB 1 DB 2
OUTPUTS INPUTS
C2 Rear

S86A Sense Trigger Inputs

The C2's PG, DB1, and DB2 outputs can be used to trigger automated events utilizing the
S86A's Sense Inputs. A specific VIA! Touch Panel can, for example, display a specific camera
based on a doorbell push at a specific door station.
NOTE: Use a 3.5mm stereo interconnect cable for these connections.
S86A Sense Input Connections
Page Trigger
SUM PG
TRIGGERS
1
+ -
DB 1 DB 2
OUTPUTS
INPUTS
C2 Rear
Page 48
+ - + - + - +12V GND NC C NO NC C NO NC C NO NC C NO
VCO POWER RELAY 1
Figure 3-25: C2 To ELAN S86A interconnects (Part 2)
S86A
ELAN SENSE INPUTS
1 2 3 5
4
3.5mm Stereo
Interconnect Cable
2
+ -
Figure 3-26: C2 To ELAN S86A interconnects
S86A #1
IN
PAGE
TRIGGER
OUT
PG IN
PG OUT
MOH OUT
RCA
Interconnect
Cable (Stereo)
IN OUT
L
R
RELAY 2 RELAY 3 RELAY 4 AUDIO LOOP
S86A Sense Input Connections
DB1/DB2 Triggers
6
SUM PG
DB 1 DB 2
OUTPUTS
C2 Rear
© ELAN Home Systems 2009 • All rights reserved.
E L A N H O M E S Y S T E M S
3.5mm Mono S86A #2
Interconnect Cable
IN
Interconnect Cable
PAGE
TRIGGER
OUT
PG IN
RCA
PG OUT
Interconnect
Cable (Mono)
MOH OUT
Interconnect
Cable (Mono)
PG/DB OUT
MOH IN
(MONO)
ELAN SENSE INPUTS
1 2
3.5mm Stereo
Interconnect Cables
TRIGGERS
1 2
+ - + -
INPUTS
3.5mm Mono S86A #3
IN
PAGE
TRIGGER
OUT
PG IN
RCA PG OUT
MOH OUT
S86A
3 4 5 6
