Summary of Contents for Elan VSOS
- Page 1 VSOS 100 WATT HIGH POWER STEREO VOLUME CONTROL w/OVERRIDE VMOS 100 WATT HIGH POWER MONO VOLUME CONTROL w/OVERRIDE...
- Page 2 This ELAN Volume Control is NTRL certifi ed to comply with local building codes. Use Class 2 wiring and methods per National Electrical Code NFPA70. Install in a Listed electrical box.
-
Page 3: Table Of Contents
VSOS ..........5 VMOS Impedance Match Settings ....6 ....7 Impedance Match Switches Page & Doorbell Level Adjustment ..8 Installation .........9 Operation ..........11 Troubleshooting ........12 Specifi cations ........13 Warranty ......Back Page Page 1 © ELAN Home Systems 2007 • All rights reserved. -
Page 4: Introduction
ELAN HOME SYSTEMS INSTALLATION MANUAL Introduction The ELAN VSOS High Power Stereo Volume Control w/ Override is a twelve-step stereo Volume Control with Variable Impedance Match settings. The VMOS is a High Power mono Volume control w/ Override conforming to the same specifi ca- tions (except stereo capability). -
Page 5: Rough-In
ELAN HOME SYSTEMS INSTALLATION MANUAL Rough-In The VSOS/VMOS will fi t into the majority of single-gang boxes. This Volume Control should not be mounted in the same rough- in box as primary or mains volt devices, i.e. 110v, 240v--this can cause undesirable noise in the speakers. -
Page 6: Wiring
ELAN HOME SYSTEMS INSTALLATION MANUAL Wiring Wiring for the VSOS/VMOS consists of speaker wire and CAT5 (if using an ELAN Communications device such as a COM2 or MAC24). The VSOS/VMOS can accommodate from 14 to 24 gauge speaker wire. Typical installations will use 16 or 18 gauge stranded copper wire, while longer runs (greater than 80 feet) should use 14 gauge wires. -
Page 7: Vsos
Override To Speakers R1R2R3R4R5R6 VSOS Impedance PG/DB Match Switch Level Adjust Impedance Match Switch PG/DB Level Adjust VC+ VC- +AMP- -SPKR+ VMOS Volume Control From To Speaker Override Amplifier Page 5 © ELAN Home Systems 2007 • All rights reserved. -
Page 8: Impedance Match Settings
ELAN HOME SYSTEMS INSTALLATION MANUAL Impedance Match Settings Switch settings on the VSOS/VMOS determine the Impedance Match settings. See diagram for position of Override Jumpers. Switch position depends on three things: 1. The minimum impedance rating of the amplifier being used. -
Page 9: Impedance Match Switches
Same Position Never create settings that cause the amplifi er to see an imped- ance below its minimum impedance rating as this can cause damage to the amplifi er. Page 7 © ELAN Home Systems 2007 • All rights reserved. -
Page 10: Page & Doorbell Level Adjustment
ELAN HOME SYSTEMS INSTALLATION MANUAL Page & Doorbell Level Adjustment When utilizing ELAN’s Page and Doorbell features, it will be necessary to adjust the Page & Doorbell Volume level. Locate the Page & Doorbell Volume jumpers as shown on the diagram below. -
Page 11: Installation
L +/-, R +/- scheme. 7. Carefully place the Volume Control in the rough-in box making sure not to put strain on the speaker / amplifier connections. Page 9 © ELAN Home Systems 2007 • All rights reserved. - Page 12 INSTALLATION MANUAL 8. Insert two 1" screws into the mounting holes of the VSOS/VMOS to mount the unit into the rough- in box. Tighten these screws until the unit is at the proper depth to mount flush with the wall.
-
Page 13: Operation
ELAN HOME SYSTEMS INSTALLATION MANUAL Operation Once the VSOS/VMOS is connected to both amplifier and speak- ers, adjustment and testing can occur. When using a receiver or integrated amplifier with it's own Volume functions, turn the Volume all the way down. Turn Volume all the way up on the VSOS/VMOS, then slowly adjust the Volume on the receiver untill a comfortable listening level is obtained. -
Page 14: Troubleshooting
See Imp. Match Section Impedance Match starting on pg.5 and set settings switches correctly Isolate to source or room 4. Incorrect and correct assignment of left/right source RCA cables or speaker cables Page 12 © ELAN Home Systems 2007 • All rights reserved. -
Page 15: Specifications
Impedance Setting (VMOS).....Variable 2X/4X/8X/16X Minimum Speaker Load........... 4 ohms Dynamic Range......49 dB (Max to Min audible) Available in White. Trim kits available in White, Ivory, Almond, Light Almond, Black, and Brown Page 13 © ELAN Home Systems 2007 • All rights reserved. -
Page 16: Warranty
Limited Lifetime Warranty ELAN HOME SYSTEMS, L.L.C. (“ELAN”) warrants to the original retail purchaser that the VSOS-VMOS Volume Control is free from defects in materi- als and workmanship, provided that the product was purchased from an authorized ELAN Home Systems Dealer. - Page 17 MATERIAL: 60 LB WHITE COATED PAPER SCALE: 1-1 SIZE: 7.000 X 4.500, TOL: +/- .040 FOLDING: ALBUM FOLD CENTER STAPLE FOLD TO 3.500 X 4.500 PAGES: 16 NOTE: ARTWORK CREATED BY ELAN HOME SYSTEMS THIS MANUAL MUST BE ROHS COMPLIANT...
