Elan Home Systems 2009 • All Rights Reserved - Elan C2 Communications Controller Installation Manual

C2
INSTALLATION MANUAL
C2
Blue
White/Blue
Orange
White/Orange
Green
White/Green
Brown
Door Station
White/Brown
Bus
Standard ELAN RJ-45 Pin-Out
TAB
C2
Blue
White/Blue
Orange
White/Orange
Green
White/Green
Brown
Door Station
White/Brown
Bus
Standard ELAN RJ-45 Pin-Out
TAB
CAUTION:
Page 34
To
Video
Switcher
Blue
White/Blue
Orange
White/Orange
Cat-5
Green
White/Green
Brown
White/Brown
DOOR LATCH
POWER SUPPLY
To 110V AC
PIN # COLOR CODE
1 BLUE
2 WHITE/BLUE
3 ORANGE
4 WHITE/ORANGE
5 GREEN
6 WHITE/GREEN
7 BROWN
8 WHITE/BROWN
CABLE
Figure 3-8: C2 to DSC3 Door Station Wiring Pinout (Option 1)
VBRM Video Balun
To Video
Switcher
Video
Snap lock
connector
Blue
White/Blue
Orange
White/Orange
Cat-5
Green
White/Green
Brown
White/Brown
Use for run from
0 to 500 feet max.
DOOR LATCH
POWER SUPPLY
To 110V AC
PIN # COLOR CODE
1 BLUE
2 WHITE/BLUE
3 ORANGE
4 WHITE/ORANGE
5 GREEN
6 WHITE/GREEN
7 BROWN
8 WHITE/BROWN
CABLE
Figure 3-9: C2 to DSC3 Door Station Wiring Pinout (Option 2)
DO NOT combine these two methods on a single destination.
VBRM Video Balun
External
12VDC
Power
Video Power
Snap Lock
Connector
*White/Brown
DS -
DS+ *Brown
*White/Green
*Green
White/Orange
Orange
White/Blue
Blue
* Splice White/Green with White /Brown
VID + and Green with Brown VID - for
camera runs between 500 &1000 feet.
Use for run from
0 to 1000 feet max.
ELECTRONIC DOOR LATCH
RELEASE MECHANISM
+
22/24AWG
4-twisted pair
shielded
wire
-
LOW VOLTAGE
OUTPUT
External 12VDC
Power
Power
DS -
DS+
White/Brown
Brown
RJ-45
White/Green
Green
White/Orange
Orange
White/Blue
Blue
ELECTRONIC DOOR LATCH
RELEASE MECHANISM
-
+
© ELAN Home Systems 2009 • All rights reserved.
E L A N H O M E S Y S T E M S
PWR
GRD
PWR
Cat-5
GRD
VID-
VID+
DS -
DS+
Butt Splice
To EXT.
DOORBELL
VID PWR
DSC3 DOOR
STATION
PWR
GRD
PWR
Cat-5
GRD
VID-
VID+
DS -
DS+
Butt Splice
To EXT.
DOORBELL
VID PWR
DSC3 DOOR
STATION
