C2
INSTALLATION MANUAL
The C2 and Your Phone Line
Where Do You Install It?
The C2 Controller installs on your phone line before all the telephones. This installation
assures that you will be able to utilize the C2's telephone and intercom features from any
phone in your home. The C2 is typically installed close to the home's whole-house audio
system or stereo system components. The C2 provides communications features for up to
two separate phone lines from your local telephone provider.
The best thing about the C2 Communications Controller is that it does not require special
or proprietary phones. Any touch-tone phone, including cordless, are all that is required for
convenient, easy to use intercom and call features!
Features
Paging
The C2's "Page" feature makes communicating to all rooms in your home as easy as
picking up a phone. The C2's page audio is heard through the same speakers that provide
music throughout your home.
Phone-to-Phone Intercom
After paging a family member, a room-to-room phone conversation can be conducted without
being heard over the in-wall speakers when the second user picks up a handset on the same line.
Music-On-Hold
Callers who are placed on hold enjoy music via the C2's "Music-On-Hold" feature
(dedicated Music-On-Hold source required).
Door Station Communication & Chimes
The C2 provides two-way communication and door chimes for up to eight dwelling
entrances. With the addition of an ELAN DSC3, DSS3 or DSF3 Doorstation Assembly, you
can conduct two-way conversations with any door station via your telephone. When someone
presses the ELAN doorbell button, a chime will sound over the speakers in every room. There
are ten selectable door chimes to choose from, so you can immediately identify which
entrance has a visitor.
Selectable Door Chimes
The C2 features 10 user-selectable door chimes that let you differentiate between door
stations. Unique chimes, such as sleigh bells, a fog horn and even a barking dog make for fun
door announcements that can easily be changed for the occasion. Here are the available door
chimes:
• 01 - 8-Note Bells (Door Station 1 default)
• 02 - 4-Note Bells (Door Station 2 default)
• 03 - 3-Note Bells (Door Station 3 default)
• 04 - 2-Note Bells (Door Station 4 default)
• 05 - "Ding-Dong"
• 06 - Fog Horn
• 07 - Mean Dog Barking
• 08 - Sleigh Bells
• 09 - Ping
• 10 - Sonar Blip
Page 12
E L A N H O M E S Y S T E M S
© ELAN Home Systems 2009 • All rights reserved.
