24
13. When the system reaches temperature lock, wait an additional
20 minutes and then begin acquiring data in focus mode.
14. Adjust the focus for the best image or spectral lines. If you are using
WinSpec/32, you may want to use the Focus Helper function for
spectroscopy applications. If you are using LightField, you may
want to use the Align Spectrometer function.

Figure 3. Typical Imaging Experiment Layout with Air-cooled Camera

Figure 4. Typical Spectroscopy Experiment Layout with Air-cooled Camera

®
ProEM + System Manual
Action
Version 1.B
Reference
Chapter 5 Operation: for
WinX, see page 43 or 47;
for LightField page 53 or
57
Chapter 5 Operation: for
imaging or spectroscopy in
WinX, see page 43 or 48 ;
for LightField, see page 53
or 58
