118

WinX or LightField Crashes When Adding GigE Camera to System

If you have a dual port Intel Pro/1000 Ethernet card and WinX or LightField crashes
when trying to add a GigE camera to the system, you will need to modify the default IP
address for one of the ports.
To Modify the Default IP Address for a Port:
1. Click on the Windows Start button and click on Control Panel .
2. On the Control Panel , click on Device Manager .
3. After the Device Manager opens, scroll down until PRO/1000 Grabber
4. Click on that label to expand it and then right-click on one of the ports. On the
5. On the Settings tab, change the third number from the left in the IP Address .
ProEM

Figure 78. Windows Start button

Devices (or similar label) appears.

Figure 79. Device Manager dialog

popup menu, click on Properties .
For example, replace the " 2 " in the IP Address 192.168. 2 .1 with " 4 " so the IP
Address is now 192.168. 4 .1
®
+ System Manual

Figure 80. Right-Click menu

Version 1.B
