Installation Overview
The list and diagrams below briefly describe the sequence of actions required to
install your system and prepare to gather data. Refer to the indicated references for
more detailed information.
1. If the system components have not already been unpacked, unpack
them and inspect their carton(s) and the system components for
in-transit damage.
2. Verify that all system components have been received.
3. If the components show no signs of damage, verify that the
appropriate power cord has been supplied with the power supply.
4. If the Ethernet adapter card provided with the system is not already
installed in the host computer, install it.
5. If the application software is not already installed in the host
computer, install it.
6. Depending on application, attach lens to the camera or mount the
camera to a spectrograph.
7. With the power supply disconnected from the camera, connect the
Ethernet cable to the GigE connector on the rear of the camera and
to the Ethernet port on the installed Ethernet card.
8. Air-Cooled System: Plug the power supply into the rear of the
camera and plug the power supply into the power source.
Liquid Cooling (optional): Make the hose connections to the
camera and plug the circulator into the power source. Add coolant if
necessary. Turn on the circulator.
9. Turn the camera ON.
10. Turn on the computer and begin running the application software.
11. Enter the hardware setup information.
12. Set the target array temperature.
Action
Chapter 3
Reference
Chapter 4 System Setup,
page 27
Chapter 4 System Setup,
page 28
Chapter 4 System Setup,
page 28
Refer to the manufacturer's
instructions
Chapter 4 System Setup,
page 35 & Software manual
Chapter 4 System Setup,
page 30
Appendix C Mounting the
ProEM+ to a Spectrograph,
page 131
Chapter 4 System Setup,
page 34
Software manual
Software manual
Chapter 5 Operation,
page 64
23
