Basic Specifications
Note: This appendix provides some of the basic specifications of a ProEM+ system. If
the information you are looking for is not here, it may be available in Appendix B,
"Outline Drawings" or on the appropriate data sheet. Data sheets can be downloaded
from the Princeton Instruments website (www.princetoninstruments.com).

Window

UV grade fused-silica (.125"/ 3.18 mm thick). Princeton Instruments offers a choice of
multi-layer VIS-AR, UV-AR, and NIR-AR coating options on the vacuum window. For
enhanced sensitivity in the UV region, proprietary Unichrome
available. For broadband applications, a choice of MgFl
available upon request.

CCD Arrays

CCD
Image Type
Resolution
Pixel Size
Active Area
Frame Rate
Spectral Rate
(@ 8 MHz)
Readout
Amplifiers Ports)
EM Digitization
(Readout) Rate
Low Noise
Digitization
(Readout) Rate
Note: The arrays listed and the specifications provided are those that were available at
the time that the manual was written. For current arrays and specifications, refer to the
ProEM+ data sheets that you can download from www.princetoninstruments.com.
ProEM+:512B ProEM+:512BK ProEM+:1024B ProEM+:1600
e2v CCD97B PI Proprietary
Monochrome Monochrome
512 x 512 512 x 512
16 µm x 16 µm 16 µm x 16 µm
8.2 mm x 8.2 mm 8.2 mm x 8.2 mm
with on chip mask
> 34 > 40 fps (full
frame)
fps (full frame)
2 2
5 MHz, 10 MHz 5 MHz, 10 MHz
100 kHz, 1 MHz, 100 kHz, 1 MHz,
5 MHz 5 MHz
Appendix A
TM
coating of the CCD is
or broadband AR coating is
2
ProEM+:1600
e2v CCD201B PI Proprietary
Monochrome Monochrome
1024 x 1024 1600 x 200
1600 x 400
13 µm x 13 µm 16 µm x 16 µm
13.3 mm x 13.3 mm 25.6 mm x 3.2 mm
25.6 mm x 6.4 mm
> 8.5 fps (full
frame)
> 1300 fps (full
vertical binning)
> 950 fps (full
vertical binning)
2 2
5 MHz, 10 MHz 1 MHz, 4 MHz,
8 MHz
100 kHz, 1 MHz, 100 kHz, 1 MHz
5 MHz
(2)
(4)
121
