Mounts

C-mount: Standard threaded video mount
Spectroscopy-mount: Flange-mount 3.60"
C- to Spectroscopy-mount adapter: Optional
Adjustable C- to Spectroscopy-mount adapter: Optional

Focal Distance (Optical)

C-mount, Front Surface to Focal Plane:
Spectroscopy-mount, Front Surface to Focal Plane: 0.590" (14.99 mm)

Camera

Cooling: Thermoelectric; air or circulating coolant
Coolant Ports: The inlet/outlet ports on the side of the camera allow you to connect the
camera to an external coolant circulator. Two 10 mm (3/8") ID, 3 meter (10 ft)
coolant hoses with the appropriate fittings for the ProEM+ are supplied with each
system. This pair of hoses with ProEM+ fittings (part number 2550-0630) can also be
ordered separately.
Additional ProEM+-compatible female barbs (part number VL2-F10B-P) are available
from Koolance (www.koolance.com). Refer to your circulator's documentation for
information about circulator-compatible fittings.
CCD Operating Temperature:
Temperature Stability: ±0.05°C; closed-loop stabilized-temperature control
Gain: Software-selectable [1 (low), 2 (medium), 3 (high)]
Dimensions: See Appendix B, "Outline Drawings" (page 125).
Weight: Approximately 8.5 lbs (3.9 kg)
Connectors:
Gig-E: Gigabit Ethernet connector.
Shutter: LEMO
ProEM+ System Manual
CCD Size
512 x 512
1024 x 1024
1600 x 200
1600 x 400

Table 5. Default Operating Temperature

®
connector provides the shutter drive pulses for driving a Princeton
Instruments-supplied 25 mm external shutter in lieu of integrated shutter. Camera
power must be OFF before connecting to or disconnecting from t his connector.
Cable not supplied.
Caution: When there is an installed internal shutter, this connector cannot drive an
external shutter.
0.690" (17.53 mm)
Default
-70°C
-55°C
-60°C
-60°C
