Ext Sync: 0 to +3.3 V logic level input to allow data acquisition to be synchronized
Logic Out: 0 to +3.3V programmable logic level output (TTL-compatible). The
Power Connector:
Power Supply: 90-240 VAC, self-switching, 140 W. DC power to the camera and TE
cooler is provided by the power supply via the Power connector on the rear of the
camera.
Fan: 24 CFM fan capacity at full power.

Options

A partial listing of options includes the WinView/WinSpec application software and
manual, the LightField application software and PDF manual, Scientific Imaging
ToolKit™ (SITK™) for LabVIEW
C- to spectroscopy-mount adapter, and the CoolCUBE
factory for more information regarding options available for your system.
Basic Specifications
with external events. Trigger edge can be positive- or negative-going as set in
software. Synchronization and Timing Modes are discussed in Chapter 6. MCX-
to-BNC adapter cable is supplied with system.
output of this connector can be programmed and can also be inverted via the
application software. For detailed information about each output signal, please
see "LOGIC OUT Control" (page 85). MCX-to-BNC adapter cable is supplied
with system.
Pinout:
A1 TEC Return
A2 TEC Power
1 INT Return
2 +24V In
3 INT Out
4 +24V In Return 1
5 +24V In Return 2
®
, C-mount to spectroscopy mount adapter, adjustable
coolant circulator. Contact the
