Ir Left Cover/Rear Left Cover/Left Cover - Develop ineo 250 Service Manual Field

7. Other
7.3.9

IR Left Cover/Rear Left Cover/Left Cover

[1]
[2]
[4]
1. Remove the Upper Rear Cover.
50
2. Remove the IR Left Cover [1].
3. Remove two screws [2] and the Rear Left Cover [3].
4. Remove the Rear Cover.
51
5. Remove the Paper Output Cover.
52
6. Remove three screws [4] and the Left Cover [5].
54
Field Service Ver. 1.0 Aug. 2005
[3]
[5]
4040F2C670DA
