Develop ineo 250 Service Manual Field page 526

Field Service Ver. 1.0 Aug. 2005
MODE
Bit:
772
Bit Feature
7 T1 timer for automatically
receiving packets
6
5
4
3
2
1
0
MODE
Bit:
773
Bit Feature
7 T1 timer for manually
sending packets
6
5
4
3
2
1
0
Factory setting bit
7 6 5 4 3 2 1 0
0 0 1 0 0 0 1 1
Logic
0 1
Bit 7-0: 00000000 Not available
00000001 1 sec
00100011 35 sec
11111111 255 sec
Factory setting bit
7 6 5 4 3 2 1 0
0 0 1 0 0 0 1 1
Logic
0 1
Bit 7-0: 00000000 Not available
00000001 1 sec
00100011 35 sec
11111111 255 sec
HEX:23
Description
|
|
HEX:23
Description
|
|
11. Soft Switch List
157
