Field Service Ver. 1.0 Aug. 2005

System Mounted with PC-402

[1] Switch Back Unit Sensor

[2] Duplex Unit Upper Transport Sensor PC24

[3] Paper Exit Sensor

[4] Synchronizing Roller Sensor

[5] Duplex Unit Lower Transport Sensor PC25

[6] Vertical Conveyance Sensor

[7] Vertical Conveyance Sensor

[8] Paper Feed Sensor

18. Jam Display
