Develop ineo 250 Service Manual Field page 123

7. Other
[26]
[25]
16. Remove the pulley tape.
18. Readjust the position of the Exposure Unit.
212
84
15. Wind Scanner Drive Cable 3 around
[27]
4040F2C726DA
17. Mount the cable to the Exposure Unit
[28]
4040F2C727DA
Field Service Ver. 1.0 Aug. 2005
pulley H [25] and pulley F [26] and
hook the bead to the side surface
[27] of the Scanner Frame.
[28].
