2. Periodical check
[5]
2.1.5

Cleaning of Miscellaneous Rollers

[1]
[4]
[5]
8
[5]
[5]
4344F2C512DA
[2]
4344F2C519DA
[3]
4344F2C520DA
[5]
[5]
4344F2C521DA
[6]
4344F2C530DA
Field Service Ver. 1.0 Aug. 2005
5. Open the Duplexing Document
Feeder.
6. Using a soft cloth dampened with
alcohol, wipe the roll [5].
1. Open the Upper Door [1].
2. Using a soft cloth dampened with
alcohol, wipe the roller [2].
3. Lift up the Original Feed Tray [3].
4. Using a soft cloth dampened with
alcohol, wipe the roller [4].
5. Remove the Front Cover and Rear
Cover.
11
6. Disconnect eight connectors [5] on
the board.
7. Remove the lever [6].
