9. Jam Display
9.3.5

Finisher Bundle Exit Misfeed

A. Detection Timing
Type
Finisher Bundle Exit
misfeed detection
B. Action
Storage Tray Detecting Sensor (PC8-FN)
Exit Motor (M1-FN)
Step
1 Initial check items
2 PC8-FN I/O check
3 Change PWB-A FN
40
The Storage Tray Detecting Sensor (PC8-FN) is not unblocked even after
the set period of time has elapsed after the Exit Motor (M1-FN) is ener-
gized.
Relevant Electrical Parts
Action
PWB-A FN PJ13A FN-8 (ON)
Field Service Ver. 1.0 Aug. 2005
Description
Main Control Board (PWB-A FN)
WIRING DIAGRAM
Control Signal
-
-
Location
(Electrical Component)
-
FS-508 G-8
-
