Develop ineo 250 Service Manual Field page 468

Field Service Ver. 1.0 Aug. 2005
MODE
Bit:
288
Bit Feature
7 Insert dummy data before
PIX.
6
5
4
3
2
1
0
MODE
Bit:
310
Bit Feature
7 Increase of sound level *
NOTE
• The features with (*) are settable by users. *: Screen setting
MODE
Bit:
311
Bit Feature
7 Invert screen *
6 Displaying next screen
when using Enlarge Dis-
play <*>
NOTE
• The features with (*) are settable by users. *: Screen setting <*>: Soft switch setting
Factory setting bit
7 6 5 4 3 2 1 0
1 1 1 1 1 1 1 1
Logic
0 1
Bit 7-0: 00H
01H
07H
FFH
Others
Factory setting bit
7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0
Logic
0 1
Normal Increased
sound sound
level level
mode mode
Factory setting bit
7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0
Logic
0 1
Normal Inverted
Wait for Display
specifi- upper-left
cation screen
11. Soft Switch List
HEX:FF
Description
Add 200 ms • Changes not allowed.
• Specify period to
transmit dummy data
Add 300 ms
before transmitting
(200 ms +
PIX.
100 ms)
• Add the period speci-
fied here to the first
flag (EMC) and FILL
Add 900 ms (G3) of the image sig-
(200 ms +700 nal.
ms)
Add 200 ms
Not available
HEX:00
Description
HEX:00
Description
