7. Other
[7]
[5]
7.3.3

Upper Rear Cover

[3]
7.3.4

Rear Right Cover/Front Right Cover

[4]
[3]
1. Open the Right Door.
2. Remove two Screws [1], and remove the Rear Right Cover [2].
3. Remove the Screws [3], and remove the Front Right Cover [4].
50
3. Remove the four screws [5], one
wave washer [6], and the Tray Rear
Cover [7].
CAUTION
• Make sure that the wave washer is
[6]
installed at the correct position.
4040F2C660DA
1. Remove three screws [1] and, push-
[2]
ing down the actuator [2], remove the
Upper Rear Cover [3].
[1]
4040F2C662DA
Field Service Ver. 1.0 Aug. 2005
[2]
[1]
4040F2C663DA
