Field Service Ver. 1.0 Aug. 2005
Maintenance
2.

Periodical check

2.1

Maintenance procedure (Periodical check parts)

NOTE
• The alcohol described in the cleaning procedure of Maintenance represents the
isopropyl alcohol.
2.1.1 Cleaning of the Rollers and Rolls
[2]
2. Remove the Crease Unit.
8
[3]
3. Service tool
3.1 CE Tool list
Tool name
Stapler Unit Positioning Jig
[1]
[2]
4511F2C502DA
[4]
4511F2C506DA
Shape
2. Periodical check
1. Using a soft cloth dampened with
alcohol, wipe the roller [1] and roll
[2].
3. Using a soft cloth dampened with
alcohol, wipe the roller [3] and roll
[4].
Personnel Parts No.
1 4511-7901-01
Remarks
3
