Field Service Ver. 1.0 Aug. 2005 7. Other
7.3.10

Rear Manual Bypass Cover/Front Manual Bypass Cover/Lower Right Cover

[5]
[4]
[2]
[3]
[1]
[6]
4040F2C671DA
1. Remove two screws [1] and the Rear Manual Bypass Cover [2].
2. Remove the screw [3] and the Front Manual Bypass Cover [4].
3. Remove the Manual Bypass Unit.
71
4. Remove two tabs [5] and the Lower Right Door Cover [6].
