8.3.3

Misfeed at Transport section

A. Detection timing
Type
Detection of misfeed at
Transport section
Detection of paper left in
Transport section
B. Action
Paper Feed Motor (M1-ADF)
Transport Motor (M2-ADF)
Registration Sensor (PC9-ADF)
Original Detection Sensor (PC8-ADF)
Step
1 Initial check items
2 PC9-ADF I/O check
3 PC8-ADF I/O check
4 M1-ADF operation check
5 M2-ADF operation check
6 Change PBA-CONT
8.3.4

Misfeed at Turnover section

A. Detection timing
Type
Detection of misfeed at
Turnover section
B. Action
Transport Motor (M2-ADF)
Registration Sensor (PC9-ADF)
Step
1 Initial check items
2 PC9-ADF I/O check
3 M2-ADF operation check
4 Change PBA-CONT
The Original Detection Sensor (PC8-ADF) is not blocked even after the set
period of time has elapsed after the Registration Sensor (PC9-ADF) is
blocked by the paper.
The Original Detection Sensor (PC8-ADF) is not unblocked even after the
set period of time has elapsed after the Registration Sensor (PC9-ADF) is
unblocked by the paper.
Relevant Electrical Parts
Action
PBA-CONT CN7CONT-3 to 6
PBA-CONT CN8CONT-3 to 6
The Registration Sensor (PC9-ADF) is not blocked even after the set period
of time has elapsed after the Transport Motor (M2-ADF) is energized.
Relevant Electrical Parts
Action
PBA-CONT CN8CONT-3 to 6
Description
Main Control Board (PBA-CONT)
WIRING DIAGRAM
Control Signal
-
PBA-CONT CN6CONT-3
PBA-CONT CN6CONT-6
-
Description
Main Control Board (PBA-CONT)
WIRING DIAGRAM
Control Signal
-
PBA-CONT CN6CONT-3
-
8. Jam Display
Location
(Electrical Component)
-
DF-605 G-3
DF-605 G-3
DF-605 C-6
DF-605 C-6
-
Location
(Electrical Component)
-
DF-605 G-3
DF-605 C-6
-
