Field Service Ver. 1.0 Aug. 2005
7.3.5

IR Right Cover/Rear Cover

[1]
[2]
[2]
1. Open the Right Door.
2. Remove the Upper Rear Cover.
50
3. Remove the IR Right Cover [1].
4. Remove thirteen Screws [2], and remove the Rear Cover [3].
7.3.6

Front Door

[3]
[1]
1. Open the Front Door [1].
2. Remove the screw [2], C-clip [3], and
the Front Door [1].
[2]
4040F2C665DA
7. Other
[2]
[2]
[3]
4040F2C664DA
51
