RED ONE Operation Manual page 97

1. Insert or connect media to camera.
Insert the CF card with the manufacturer's label facing outward (away from camera body). Push
-
the CF firmly into the CF slot, but without using excessive force to prevent damage.
Or attach a RED-DRIVE® or RED-RAM® magazine to the DRIVE connector (e-SATA port) located
-
on the rear of the camera using the 16-pin e-SATA cable provided.
2. When a CF card is inserted into the camera or RED-DRIVE® or RED-RAM® magazine is connected,
the camera will recognize the media is unformatted and display "DISK UNFORMATTED" in the LCD
display and the lower left corner of the external monitors will display "UNFORMATTED".
3. To format the media push the
4. Select MEDIA and press Joystick in or down to enter. Camera LCD will display SYSTEM MEDIA
Menu.
Build 20 v20.1.6
OCTOBER 19, 2009
menu button.
SYSTEM
©2009 RED.COM INC.
95
