REAR OF CAMERA

A
B
Build 20 v20.1.6
OCTOBER 19, 2009
C
D
Camera DC Power Input
11.5 – 17V
e-SATA Interface (to RED-
DRIVE or RED-RAM digi-
tal magazine)
©2009 RED.COM INC.
A
C Aux Power / GPIO A
D Aux Power / GPIO B
B
