2. VOLUME box will highlight to allow you to choose a volume level between -6.0dB and 6.0dB (default
is 0dB).
3. Twist joystick to change the highlighted VOLUME box to the desired setting.
4. Move joystick left, right or up to select and exit.
NOTE The RED-ONE
:
TM
proximately 1 minute digital recording of a reference level Tone Generator provided by an external
signal source may be used as a substitute for an internal Tone Generator.
NOTE Before digital audio recordings can be made, audio inputs need to be enabled.
:

48V ENABLE

Push to access the channels that you wish to provide 48V Phantom Power on.
48V ENABLE
NOTE: With firmware prior to Build 18, and all cameras with Rev A audio hardware, the +48V Phan-
tom Power output will be disabled each time the camera is power cycled.

MEDIA MENU

This menu provides various media management functions including digital media formatting. Options
available are PRE-RECORD, UNMOUNT, FORMAT, CHANGE and RESET. For detailed instructions on
formatting, copying and deleting files from media, go to

PRE-RECORD

Pre-Record enables a continuous loop recording of definable duration (10 or 30 seconds) that permits
continuous video and audio capture "before the event" i.e. before RECORD is pushed.
When enabled, pre-record starts recording 1-second chunks of video and audio to the digital magazine.
At the end of the selected pre-record period, the first chunk is overwritten.
If the RECORD button is pushed while in pre-record, pre-record mode is terminated and a normal record
is enabled. The timecode value and clip name are carried over between modes.
56 56
camera does not provide a reference level Tone Generator. However an ap-
©2009 RED.COM INC.
APPENDIX B: MANAGING DIGITAL MEDIA.
Build 20 v20.1.6
