AUDIO / VIDEO MENU CONTROLS

This section describes monitor path parameters such as viewfinder, and RGB color and gains. These pa-
rameters are accessed from the VIDEO menu access key.
Available sub menus include VIEW, VIDEO, VIEWFINDER, AUDIO and HEADPHONE. To access the AV
MENU push the VIDEO menu button on the rear of the camera. To enter the available sub-menus, use the
joystick to highlight the desired selection and push joystick in or down.

VIEW

The VIEW sub menu allows the user to choose the mode of monitor path image processing. Choices are
REDspace, REC 709 and RAW. To adjust: Select VIEW and twist joystick to change the highlighted CO-
LOC box to the desired setting (default is REDspace.)
REDspace: Monitor path image processing uses custom REDspace tonal response curve.
REC709: Monitor path image processing uses SMPTE REC 709 tonal response curve.
RAW: Monitor path image represents the RAW sensor data, bypassing the color matrix.

VIDEO

The four available submenus are LOOK, COLOR, GAIN and TONE.
NOTE: Color and Gain and Tone values used by the monitor path are stored as metadata for use in
REDCODE™ RAW compatible image processing applications. They can be used to visualize a spe-
cific color "look" but do not affect the REDCODE™ RAW recorded data.

LOOK

The LOOK menu permits Video, Gain and Tone values to be exported or imported from an SD Card. Look
files may be read by another camera, but not RED Alert! ® or REDCINE®. Push joystick down or in to se-
lect desired change.
