PREVIEW HD-SDI

A single DIN 1.0/2.3 connector labeled PVW provides a high definition video preview output.
Pin:
Center
Shield/Screen
Note: If PREVIEW type is set to MENUS (DVI) the PVW output is disabled.
In record, the Preview output provides a 1280 x 720p 10-bit 4:2:2 progressive scan video, at 59.94 or
50.00 Hz.
In playback, if PLAYBACK is set to 720p, the Preview output provides a 1280 x 720p 10-bit 4:2:2 pro-
gressive scan video, at 59.94 or 50.00 Hz.
If PLAYBACK is set to 1080p, the Preview output provides a 1920 x 1080p 10-bit 4:2:2 progressive scan
video signals at 23.98, 24.00, 25.00, or 29.97 Hz.
NOTE: the Preview HD-SDI output provides 4 channels of embedded audio plus timecode.
NOTE: The embedded timecode value is equal to the Time Code value of the recorded frame pre-
viewed by the PVW output. I.e. the timecode sequence will be discontinuous.
NOTE: RED ONE™ outputs progressive scan video, it does not support 1080PsF format.
NOTE: If an ANAMORPHIC record mode has been selected (2K ANA, 3K ANA, 4K ANA) the video
visible on the Preview HD-SDI output has been stretched 2:1 to illustrate the final 2.40:1 aspect ra-
tio of the final image projection. The actual recorded image is 1.2:1 aspect.

HDMI

An HDMI Type A connector provides an HDTV compatible 720p video and audio signal, or a DVI / SXGA
compatible 1280 x 848 progressive scan video signal, at 50.00 or 59.94 Hz.
Selection between these two modes is made in SYSTEM / MONITOR / PREVIEW. The default setting is
VIDEO (720p). In this mode, the HDMI output replicates the HD Preview video output.
The alternative mode is MENUS (DVI). In this mode, the HDMI output is compatible with most DVI based
SXGA or higher resolution computer monitors. Use is as an external Viewfinder.
NOTE: HDMI output is not active when PLAYBACK is set to 1080p.i.e. no output is available when
the RED-ONE camera is placed into playback.
NOTE: If an ANAMORPHIC record mode has been selected (2K ANA, 3K ANA, 4K ANA) the video
visible on the HDMI output has been stretched 2:1 to illustrate the final 2.40:1 aspect ratio of the
final image projection. The actual recorded image is 1.2:1 aspect.
