Pin:
1
2
3
4
5
6
7
8
9
10
NOTE: Pins 4, 6, 9 and 10 are reserved for future use.

Viewfinder (RED EVF) Interface

The RED™ EVF interface is a custom digital video and power interconnection between the camera and a
RED™ EVF. Due to the requirement for absolute data integrity that requires custom cable construction,
the pin-out of this interface is not published.
Contact RED™ technical support for available RED™ EVF cable lengths.

Monitor (RED LCD) Interface

The RED™ LCD interface is a custom digital video and power interconnection between the camera and a
RED™ LCD. Due to the requirement for absolute data integrity that requires custom cable construction,
the pin-out of this interface is not published.
Contact RED™ technical support for available RED™ LCD cable lengths.
NOTE: The Aux/RS232, RED™ EVF and RED™ LCD connectors use the same shell size. Do not at-
tempt to force fit a 10-pin Aux/RS232 cables into a 16-pin RED™ EVF or RED™ LCD connector, or
force fit a 16-pin RED™ EVF or RED™ LCD cable into a 10-pin Aux/RS232 connector.

LINE LEVEL / MICROPHONE LEVEL AUDIO INPUTS

A three-pin mini-XLR connector is provided for each of the camera's Line / Microphone inputs. Audio is
recorded at 24-bit 48KHz, which provides high audio fidelity and wide dynamic range. The Line Level and
Microphone Level analog audio input signals are routed via a high quality A/D and pre-amplifier, whose
gain stage may be controlled using the Input Level control to achieve the desired audio reference / re-
cording level.
To assist with audio operating reference level setup, the camera provides a color-coded Peak Level meter
with 0dBu (-20dbFS) Witness Mark in the Graphical User Interface.
Peak Level meter range is –34dBu to +20dBu (-54dBFS to 0dBFS) and provides clip indication.
108 108
Signal Description
GND Camera ground
RTX RS232 Transmit Data
+12V Regulated 12V output, 500mA max.
- -- Reserved: do not connect --
SW1 "W Reserved: do not connect
- -- Reserved: do not connect --
SW2 "W Reserved: do not connect -a
RRX RS232 Receive Data
- -- Reserved: do not connect --
- -- Reserved: do not connect --
©2009 RED.COM INC.
Direction
--
Out
Out
--
In
--
In
In
--
--
Build 20 v20.1.6
OCTOBER 19, 2009
