Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Electrical system - Edition 07.2010
9.6 Removing and installing vehicle inclina‐
tion sender -G384- (up to 2006)
Vehicle inclination sender -G384- (from 2007)
The vehicle inclination sender -G384- -arrow- is located on the
right beneath the dash panel, behind the front passenger's airbag.
Note
The anti-theft alarm system must be deactivated before vehicle
inclination sender -G384- is removed
Caution
♦ Switch off ignition and all electrical consumers.
♦ Remove the ignition key.
Removing
– Remove glove compartment ⇒ General body repairs, interior;
Rep. gr. 68 .
– Unscrew bolts -1- and remove vehicle inclination sensor -
G384- from bracket.
– Detach connector -2- from vehicle level sender -G384- .
Installing
Installation is carried out in reverse order of removal.
9.7 Vehicle inclination sender -G384- (from
MY2010)
Note
The anti-theft alarm sensor -G578- includes the vehicle incli‐
♦
nation sender -G384- and the interior monitoring sensor -
G273- (two sensors).
The anti-theft alarm sensor -G578- cannot be dismantled.
♦
Removing and installing anti-theft alarm sensor -G578-
⇒ page 432 .
434
Rep. gr.96 - Lights, bulbs, switches - interior
⇒ page 431
⇒ page 430 .
