Digital Telephone System

System Manual

This publication is applicable to the following equipment:

G0408, with software I0408, revision 18A and later

G0816, with software I0816, revision 18A and later

G1632, with software I1632, revision 18A and later

Supports Impact, Impression, DigiTech,

and Scout Telephones

For The Impact DSU

Table of Contents

Chapters

Table of Contents

Need help?

Do you have a question about the G0408 and is the answer not in the manual?

Questions and answers

Summary of Contents for Comdial G0408

Page 1 System Manual For The Impact DSU This publication is applicable to the following equipment: G0408, with software I0408, revision 18A and later G0816, with software I0816, revision 18A and later G1632, with software I1632, revision 18A and later Supports Impact, Impression, DigiTech,...
Page 2 Printed in U.S.A. GCA47-157...
Page 3 Software Instructions For the Impact DSU This publication is applicable to the following equipment: G0408, with software I0408, revision 18A and later G0816, with software I0816, revision 18A and later G1632, with software I1632, revision 18A and later Supports Impact , Impression, DigiTech, and Scout Telephones Printed in U.S.A.
Page 4 Certified To The ISO 9001 Standard.  Comdial strives to design the features in our communications systems to be fully interactive with one another. However, this is not always possible, as the combinations of accessories and features are too varied and extensive to insure total feature compatibility.
Page 5: Table Of Contents
IMI66–107 Digital Telephone System Introducing The Digital Telephone System Section Title.................... Page Using This Manual ..................12 Using Related Publications.................13 1.2.1 Locating User Information ..............13 Accessory Information................15 1.3.1 The Analog Terminal Interface .............. 15 1.3.2 Headset Operation ...................15 1.3.3 Battery Back Up ..................16 1.3.4 DSS/BLF Console ...................16 1.3.5...
Page 6: Using This Manual
Digital Telephone System IMI66–107 Using This Manual This publication contains a technical discussion of the digital telephone system; it provides step-by-step instructions for installation and programming. If you are unfamiliar with the equipment, read this manual at least once before you attempt to install and program the system. The five chapters in this manual are as follows.
Page 7: Using Related Publications
IMI66–107 Digital Telephone System Using Related Publications The following publications contain information applicable to the digital telephone system. Should you need copies of these publications, contact your Comdial inside sales representative. Comdial Inside Sales Department P.O. Box 7266 Charlottesville VA 22906 Call: 1-800-347-1432 1.2.1...
Page 8 Digital Telephone System IMI66–107 Operation With Impact Telephones and Consoles These user guides are for telephones with product codes 8024S, 8124S, 8012S, 8112N, 8101N, and console IB64X. • GCA70245 Impact LCD Speakerphone System Users Guide • GCA70244 Impact Multiline Telephone System Users Guide •...
Page 9: Accessory Information
1.3.2 Headset Operation The Comdial DigiTech speakerphones with product codes of 7700S, revision H and earlier, include a built-in headset port. Speakerphones with a revision of I and later and Impact LCD speakerphones with product code 8024S provide an auxiliary jack for headset interface.
Page 10: Battery Back Up
Digital Telephone System IMI66–107 1.3.3 Battery Back Up You can install an optional battery backup that provides power to the system in the event of a power failure. For more information, see section 2.20.1, Installing The Battery Backup. 1.3.4 DSS/BLF Console You can add a separate DSS/BLF console to provide additional DSS/BLF buttons to a particular station (such as an attendant).
Page 11: Hardware Summary
2- or 4-conductor, twisted-pair cable. The digital telephone system supports all Comdial proprietary digital telephone models. NOTE: Sxxxx software only supports DigiTech telephones; Ixxxx software supports all digital telephones.
Page 12: Common Equipment Description
Digital Telephone System IMI66–107 Common Equipment Description The common equipment base unit is a fully electronic device. It is essentially a special purpose computer system acting as a communications controller between central office (CO), private branch exchange (PBX), or CENTREX supplied lines and the proprietary digital telephone stations.
Page 13 IMI66–107 Digital Telephone System 4-Line, 8-Station Base Unit 8-Line, 16-Station Base Unit CAJS 74 16-Line, 32-Station Base Unit Figure 1–1: Common Equipment Dimensions Introducing The DSU 1 – 9...
Page 14: Station Descriptions
CO, PBX, CENTREX, or common equipment. The digital telephones are available in several different styles with several models available in each style. The following list details the available telephones. 1.6.1 DigiTech Telephone Descriptions CAJS075 12X14LCD COMDIAL DIGITECH COMDIAL DIGITECH TRANS TRANS CONF...
Page 15 IMI66–107 Digital Telephone System 7.65 " 4. 3" 4. 6 " 7714X 7714S .625" 1.112" 4. 7" 6.451" 2. 7" .625" 77 1X CAJS 45 1.251" Figure 1–3: DigiTech Telephone Dimensions Introducing The DSU 1 – 11...
Page 16: Impact Telephone Descriptions
TRNS/CNF TRNS/CNF SPEAKER SPEAKER HOLD INTERCOM HOLD INTERCOM 8012S LCD Speakerphone 8112S Speakerphone CAJS076 OPER OPER COMDIAL COMDIAL TRNS/CNF TRNS/CNF HOLD INTERCOM HOLD INTERCOM 8112N Non-Monitor IB64X DSS/BLF Console 8101N Single Line Proprietary Telephone Figure 1–4: Impact Telephone Images 1 – 12 Introducing The DSU...
Page 17 IMI66–107 Digital Telephone System 7.13 1 .75 1 1N, 124 S 112N CAJS 77 4.64 3.731 112S 1. 34 Figure 1–5: Impact Telephone Dimensions Introducing The DSU 1 – 13...
Page 18: Impression Telephone Descriptions
Digital Telephone System IMI66–107 1.6.3 Impression Telephone Descriptions OPER OPER SPKR MUTE SPKR MUTE HOLD ITCM HOLD ITCM unisyn01.cdr unisyn05.cdr 2122S (22-Line Speakerphone) 2022S (22-Line LCD Speakerphone) 2122X (22-Line Monitor Telephone) unisyn09.cdr DU32X (32-Button DSS/BLF Console) 2101N (Single Line Proprietary Telephone) unisyn11.cdr Figure 1–6: Impression Telephone Images 1 –...
Page 19 IMI66–107 Digital Telephone System 4.78" 9.08" 3.94" 8.90" UNIS029 1.13" 7.130 2101N 8.900 cajs109 Figure 1–7: Impression Telephone Dimensions Introducing The DSU 1 – 15...
Page 20: Station Controls And Indicators
Rocker switch located on front face 8124S, 8012S, 8112S plate. Adjust while ringing to set volume. 7701X, 8101N, 8112N Switch on bottom housing. Set for fixed volume levels. CAJS 75A COMDIAL DIGITECH Ringer Volume Switch CAJS096 Rocker Switch TRANS CONF SPKR...
Page 21 HOLD INTERCOM Hold Button Microphone Intercom Opening Button Button CAJS107 LCD Alphanumeric Display Interactive Buttons (NOT Programmable) Auxiliary Jack (On bottom) Button Transfer/ COMDIAL DIGITECH Conference Button Speaker Mute TRANS Programmable CONF Button Buttons Speaker SPKR MUTE Button Volume Control...
Page 22 Digital Telephone System IMI66–107 LCD Display Interactive Buttons Speaker Feature Buttons, Mute Button Line Buttons, and DSS Buttons T/C Button OPER SPKR Button SPKR MUTE Message Volume Control HOLD ITCM Waiting Light cajs110 Hold Button Microphone Opening TAP Button ITCM Button Figure 1–10: Station Controls And Indicators On Impression Telephones 1 –...
Page 23: General Specifications
IMI66–107 Digital Telephone System General Specifications System Capacity G0408 G0816 G1632 GM408 Lines Stations DSS/BLF Consoles Two Per Station Two Per Station Two Per Station Two Per Station (One Per Station (One Per Station (One Per Station (One Per Station...
Page 24: Power Requirements
Digital Telephone System IMI66–107 Conferencing G0408 and G0816 G1632 Maximum Combinations 1 five-way plus 1 three-way 4 five-way plus 1 three-way at Any One Time plus 2 SOHVA plus 1 SOHVA 2 four-way plus 2 SOHVA 6 four-way plus 2 three-way...
Page 25: Music Interface
IMI66–107 Digital Telephone System Music Interface Input Level 3 Volts peak-to-peak maximum Input Impedance Approximately 500 Ohms Connector RCA phono jack Station Message Detail Recording Port Format Serial, pseudo RS-232C Parity None Data Bits 7 or 8 (programmable) Stop Bits 1 or 2 (programmable) Baud Rate Programmable in class of service...
Page 26: Feature Codes
Digital Telephone System IMI66–107 1.7.1 Feature Codes Feature Dialing Code All Call Page (Through Station Speakers) INTERCOM, 87 Attendant Calling INTERCOM, 0 Automatic Redialing Programmed Button Background Music INTERCOM, INTERCOM, # 1 Automatic Call Back Activate INTERCOM, (ext no), Cancel INTERCOM, # 6 Station-to-Station Activate...
Page 27 IMI66–107 Digital Telephone System Cancel On Line INTERCOM, Retrieve Message INTERCOM, HOLD Night Transfer (Attendant) INTERCOM, S # 03, Programmed Button INTERCOM, # 03, Programmed Button Personal Ringing Tones Set Tones 16 INTERCOM, 4 (16) Pulse/Tone Switching Redial Last Dialed Number Save Number Redial HOLD, Programmed Button Store...
Page 28: System Ringing Patterns
Digital Telephone System IMI66–107 1.7.2 System Ringing Patterns Ring Type Ring Cadence CO/PBX Line Ring Host system ring cadence Intercom Tone Signaling Two 150 msec. tone bursts every four seconds Voice Signaling alert One 215 msec. tone burst Timed hold recall at station that put call on hold Three 150 msec.
Page 29: Seeking Repair Assistance
If your common equipment cabinet or individual stations need repair, you may return the equipment to Comdial. Comdial will, at its option, either repair or replace it. There is a fixed charge for this repair. For information on this charge, call or write to the address given below.
Page 31 Grounding The Stations................2–17 2.5.2 Relocating The Stations................2–17 2.5.3 Installing The Cable Clips ..............2–17 2.5.4 Connecting Stations To The G0408 ............ 2–19 2.5.5 Connecting Stations To The G0816 ............ 2–20 2.5.6 Connecting Stations To The G1632 ............ 2–21 2.5.7 Wall Mounting The Telephone Stations..........2–23...
Page 32 Digital Telephone System IMI66–107 Section Title ......................Page Installing DSS/BLF Consoles ..............2–26 Connecting A Power Failure Station............2–28 Using The Auxiliary Equipment Interface ..........2–29 Common Audible And Auxiliary Ringing Interface......2–30 2.9.1 Connecting Outside Lines ..............2–30 2.9.2 Connecting Selected Ports ..............2–30 2.10 Using The External Paging Interface .............2–32 2.11 Using A Line Port As An External Paging Interface......2–33 2.12 Connecting Data Devices .................2–34 2.12.1...
Page 33 IMI66–107 Digital Telephone System Section Title ......................Page 2.16 Checking The System Installation ............2–51 2.16.1 Checking The Resistance..............2–51 2.16.2 Checking The Voltage ................2–51 2.16.3 Checking The General Operating Conditions ........2–52 2.17 Isolating Failures..................2–53 2.17.1 Checking The System Status Indicator..........2–53 2.17.2 Testing The Stations ................2–53 2.18 Installing The System Options And Accessories ........
Page 34: Mounting Considerations
Digital Telephone System IMI66–107 Mounting Considerations The following requirements will help you to install the digital telephone system. • Locate the equipment cabinet within four feet of an AC electrical outlet dedicated exclusively to the use of this equipment. The outlet must be a 117 VAC 15 AMP circuit with a third-wire ground supplied to a standard electrical outlet (NEMA 5–15R).
Page 35: Tools And Hardware
IMI66–107 Digital Telephone System 2.1.1 Tools And Hardware You will need the following tools and materials to install the common equipment. • Fasteners—wood screws (1/4 x 1-inch round head), toggle bolts, or wall anchors, • Screwdriver—to match fasteners, • Electric drill—if prepared holes are required, •...
Page 36: Mounting The Cabinet
Digital Telephone System IMI66–107 Mounting The Cabinet After thoroughly reviewing Section 2.1 and fully understanding its subject matter, use the following procedure to mount the common equipment cabinet 1. Unpack and carefully inspect all equipment for shipping damage. Notify the shipper immediately of any damages that you find.
Page 37 IMI66–107 Digital Telephone System 0.87" 21.30" 3.78" Back of 4-Line, 8-Station Base Unit 20.50" 4-Line, 8-Station Base Unit 0.88" 16.50" 27.58" 3.78" Back of 8-Line, 16-Station Base Unit 26.25" 8-Line, 16-Station Base Unit 0.88" 16.50" 27.58" 4.54" Back of 16-Line, 32-Station Base Unit 26.65"...
Page 38: Making The Ac Power Connection
Always replace the fuse with one of the same value and type; otherwise, equipment damage could result. Table 2–1: Cabinets And Their Fuse Types Cabinet Fuse Value G0408 1A 250V slow-blow type G0816 3A 250V slow-blow type G1632 3A 250V slow-blow type 2 –...
Page 39 IMI66–107 Digital Telephone System Dedicated 117VAC 15 AMP NEMA 5-15R electrical outlet with third-wire ground Plug-in power line surge protector (typical) CAJS079 Fuse (See text) Typical Common Equipment Grounding terminal Typical earth ground Figure 2–2: Making The AC Power Connection Installing The DSU 2 –...
Page 40: Grounding The System
Digital Telephone System IMI66–107 2.3.2 Grounding The System If spare conductors exist in the cables between the station and the 66M-xx connector blocks, it is good practice to connect them to an earth ground. Doing this may help prevent them from inducing radio frequency and/or AC interference into the system.
Page 41 IMI66–107 Digital Telephone System Be sure that all of the ground connections are without splices and are visible for inspection and maintenance. Tag all of the ground connections with a sign that reads: Do Not Remove Or Disconnect. If you install expansion modules on the base cabinet, attach at least a #10 or #12 insulated, solid copper wire between the frame ground stud on the expansion module(s) to the frame ground stud on the base cabinet.
Page 42: Connecting The Lines
The G0408, G0816 and G1632 common equipment supports the installation of up to 4, 8, or 16 lines, respectively. Add-on expansion modules are available to expand the line capacity of the systems.
Page 43 IMI66–107 Digital Telephone System (Typical 8-Line, 16-Station Base Unit Shown) 6-Wire Twisted RING 2 Pair Cable RING 1 TIP 1 TIP 2 RING 4 RING 3 TIP 3 TIP 4 CO/PBX LINES RING 6 RING 5 TIP 5 TIP 6 RING 8 RING 7 TIP 7...
Page 44: Line Connection Details
Digital Telephone System IMI66–107 2.4.1 Line Connection Details The table on the next page shows the line connection details for all three of the common equipment base units. Jacks one and two are the same for all three cabinets, jacks three and four are the same for both the G0816 and G1632 cabinets, and jacks five through eight are only available on the G1632 cabinet.
Page 45 Pin No. Connection Telephone Number Auxiliary 1 (Line 2) Tip Line 2 Tip Line 1 Tip Line 1 Ring G0408, Line 2 Ring G0816, Auxiliary 1 (Line 2) Ring Auxiliary 2 (Line 4) Tip G1632 Line 4 Tip Line 3 Tip...
Page 46: Connecting The Stations
The G0408, G0816 and G1632 common equipment supports the installation of up to eight, 16, or 32 telephones, respectively. Add-on expansion modules are available to expand the station capacity of the systems. One 4-line 8-station expansion module can be added to the G0408. The G0816 and G1632 can each take two expansion modules.
Page 47: Grounding The Stations
2.5.2 Relocating The Stations The Comdial proprietary telephones identify themselves to the system when you install them. The system assigns an extension number and all other programmable attributes to station ports as a default that you can reprogram as needed. Plus, you can use programming action to reassign attributes of one station port to a different station port if you wish.
Page 48 Digital Telephone System IMI66–107 4-Line, 8-Station Base Unit 8-Line, 16-Station Base Unit Station 10-17, Power Fail Station Grounding Terminal Grounding Terminal Station 10-25 Power Fail Station 16-Line, 32-Station Base Unit Stations 10-25 Power Fail Station Stations 26-41 CAJS084 Grounding Terminal Figure 2–6: Station Connections 2 –...
Page 49: Connecting Stations To The G0408
IMI66–107 Digital Telephone System 2.5.4 Connecting Stations To The G0408 This table shows the color-coded connections for a G0408 common equipment cabinet. Table 2–3: Connecting Stations To The G0408 Common Equipment Cabinet 25-Pair Connections Two-Wire Connections Station Connections Clip Wire Color Pair Pin No.
Page 50: Connecting Stations To The G0816
Digital Telephone System IMI66–107 2.5.5 Connecting Stations To The G0816 This table shows the color-coded connections for a G0816 common equipment cabinet. Table 2–4: Connecting Stations To The G0816 Common Equipment Cabinet 25-Pair Connections Two-Wire Connections Station Connections Clip Wire Color Pair Pin No.
Page 51: Connecting Stations To The G1632
IMI66–107 Digital Telephone System 2.5.6 Connecting Stations To The G1632 The following two tables show the color-coded connections for a G1632 common equipment cabinet. Table 2–5: Connecting Stations To J1 On The G1632 Common Equipment Cabinet 25-Pair Connections Two-Wire Connections Station Connections Clip Wire Color...
Page 52 Digital Telephone System IMI66–107 Table 2–6: Connecting Stations To J2 On The G1632 Common Equipment Cabinet 25-Pair Connections Two-Wire Connections Station Connections Clip Wire Color Pair Pin No. Pair Wire Color Station Location Term. White-Blue Green Signal Path Blue-White White-Orange Green Signal Path Orange-White...
Page 53: Wall Mounting The Telephone Stations
IMI66–107 Digital Telephone System 2.5.7 Wall Mounting The Telephone Stations The DigiTech (product code 77nnn), Impact (product code 8nnnn), and Impression (product code 2nnnn) telephones are shipped from the factory configured for desk use. To convert them for wall-mounting, follow the procedures outlined below. To convert the DigiTech model 77nnn telephones for wall-mounting, 1.
Page 54 Digital Telephone System IMI66–107 To convert the model Impact (models 80nnn and 81nnn) and Impression (models 20nn and 21nnn) telephones for wall-mounting, 1. Turn telephone over and disconnect line cord and handset cord from telephone. Do not damage line cord on plastic dressing tabs. 2.
Page 55 IMI66–107 Digital Telephone System To wall-mount the telephones, After configuring a telephone for wall mounting, either mount it directly on the wall using two #10 panhead screws (obtained locally), or mount it on a wall jack cover plate. If using a wall jack cover plate, use an AT&T type 630B wall plate for best results.
Page 56: Installing Dss/Blf Consoles
Digital Telephone System IMI66–107 Installing DSS/BLF Consoles The digital telephone system supports the installation and use of a DigiTech DD32X or Impact IB64X consoles at any available station port. The number of installed consoles is limited only by port availability; however, since a console complements a companion telephone located in an adjacent station port, you can use up to one-half of the available station ports for consoles.
Page 57 IMI66–107 Digital Telephone System While the first console (the one installed at the logic-paired port) extends the autodial buttons of the paired telephone by 48 and provides DSS/BLF coverage for station ports 10 through 57, the second console (the one installed at the programmed station port) provides DSS/BLF coverage as follows: •...
Page 58: Connecting A Power Failure Station
Digital Telephone System IMI66–107 Connecting A Power Failure Station The system provides a tip and ring pair connected to line 1 as an emergency power failure circuit. This circuit is active during a commercial AC power failure if an external battery assembly is not installed to provide battery back-up power to the system.
Page 59: Using The Auxiliary Equipment Interface
IMI66–107 Digital Telephone System Using The Auxiliary Equipment Interface You can connect an industry-standard telephone or a data device such as a modem or a FAX machine on a line ahead of the common equipment if you wish. If you do so, the system can detect an off-hook condition in the connected device and turn on the line status light at the system telephones to indicate that the line is busy.
Page 60: Common Audible And Auxiliary Ringing Interface
Digital Telephone System IMI66–107 Common Audible And Auxiliary Ringing Interface You can use the relay closure dry-contact points for controlling external audible equipment. These contact closures track the pattern of the ringing for incoming calls. The contacts are closed during the ringing period and are open during the silent period. CAUTION Do not exceed a 1 amp at 24 volts (0.5 amp at 48 volts) load on these control terminals.
Page 61 IMI66–107 Digital Telephone System Figure 2–13: Connecting Typical Common Audible Interface Wiring Installing The DSU 2 – 31...
Page 62: 2.10 Using The External Paging Interface
• Connect the audio input of a customer-supplied external paging amplifier to the paging port. • If the paging amplifier requires an enable signal, connect the enable leads to the station 17 audible terminals. J1 Connector Block (G0408 and G0816 Systems) Paging Port Typical Common...
Page 63: Using A Line Port As An External Paging Interface
IMI66–107 Digital Telephone System 2.11 Using A Line Port As An External Paging Interface You can use class of service programming to program a line port to be an AUXILIARY port. As an AUXILIARY port, a user can use it to couple a telephone to an external paging device that you have wired to the line port.
Page 64: 2.12 Connecting Data Devices
Digital Telephone System IMI66–107 2.12 Connecting Data Devices This section contains information on two stages of wiring connections for data devices. Section 2.12.1 explains connections from stations to modular jacks. Section 2.12.2 details wiring from the modular jack to the DSU by way of the punch-down-block. 2.12.1 Making Modular Jack Data Connections Modular jack connections are wiring connections from a station to a modular (wall) jack.
Page 65 IMI66–107 Digital Telephone System From RS232 Data Port A Typical modular to EIA adapter wiring shown for reference only. Typical VDT Interface Video Display Terminal Typical 625A2 Modular Jack Front View of Jack Front View of Jack 6 5 4 3 2 1 Industry Standard Modular Line Cord (4-conductor)
Page 66: Making The Common Equipment Data Connections
2.12.2 Making The Common Equipment Data Connections You must make wiring connections from the modular jack (wall jack) to the G0408 and G0816 common equipment cabinets by way of the punch-down-block, while the G1632 cabinet provides modular jacks for the data connections.
Page 67 IMI66–107 Digital Telephone System Station Connector Block Data Ports (4-line, 8-station base unit and 8-line, 16-station base unit) NOTES: Maximum distance between common equipment cabinet Modular Jack Data Ports and printer or VDT typically (16-line, 32-station base unit) limited to 500 feet. Longer distances require limited distance modems at either end of run.
Page 68: Programming With A Video Display Terminal
Digital Telephone System IMI66–107 2.12.3 Programming With A Video Display Terminal You can program the digital telephone system using a telephone or a Video Display Terminal (VDT). You can connect the VDT directly to the DSU, or you can program the system remotely using the following equipment: •...
Page 69 IMI66–107 Digital Telephone System If you experience difficulty in establishing a communications path between your VDT, modems, and the digital telephone system, note the following suggestions: • make sure that you have enabled the modem auto-answer feature, • confirm that the modems are wired correctly. Reverse connections at pins 2 and 3 if necessary, •...
Page 70: 2.13 Using The Music Interface
Digital Telephone System IMI66–107 2.13 Using The Music Interface If music is to be part of the system, connect a customer-provided music source to the common equipment music interface jack (phono jack) provided for this purpose. The impedance of this input is approximately 500Ω.
Page 71: 2.14 Using The Add-On Expansion Module
The line connections of the expansion module are available at two modular jacks. When facing the jack openings, lines 1 and 2 are provided by the jack on the right and lines 3 and 4 are provided by the jack on the left. Table 2–9: Connecting Lines To The G0408 Expansion Module Line Telephone...
Page 72: Expansion Capabilities
Digital Telephone System IMI66–107 2.14.1 Expansion Capabilities The 4-line 8-station expansion module adds station and line capability in several different combinations. 4-Line, 8-Station Base Unit 24-Port System 8-LINES AND 16-STATIONS (BASE UNIT PLUS ONE EXPANSION MODULE) 36-Port System 12-LINES AND 24-STATIONS (BASE UNIT PLUS ONE EXPANSION MODULE) 8-Line, 16-Station Base Unit 48-Port System...
Page 73: Connecting Stations To The Expansion Module
IMI66–107 Digital Telephone System 2.14.2 Connecting Stations To The Expansion Module The station connections are available at a 50-pin connector. Table 2–10: Connecting Stations To The G0408 Expansion Module 25-Pair Connections Two-Wire Connections Station Connections Clip Wire Color Pair Pin No.
Page 74: Installing The Add-On Expansion Module
Digital Telephone System IMI66–107 2.14.3 Installing The Add-On Expansion Module Each add-on expansion module measures 15.5" wide x 9.4" high x 1.6" wide and weighs approximately 4 pounds. The modules are designed so that you can attach them to the base unit and connect them to it via cabling.
Page 75 IMI66–107 Digital Telephone System Typical Base Unit (8-Line, 16-Station Base Unit) Nameplate (Remove to expose base unit connectors) Location Upper Mounting Holes (2 Places) Lower Mounting Holes (2 Places) Bottom Location AM012 Ground Connecting Cable Modules and Plug to Base Unit Securing Screw...
Page 76: 2.15 Upgrading The System Software
Digital Telephone System IMI66–107 2.15 Upgrading The System Software The following sections contain information on safety precautions you should take before working on the common equipment, procedures for making a copy of the call cost records before upgrading software, instructions for replacing the software cartridge, and instructions for master clearing the system to load the new software.
Page 77: Saving The Call Cost Records
IMI66–107 Digital Telephone System 2.15.2 Saving The Call Cost Records To save the call cost records, 1. Make a copy of the call cost records and then delete them from the system memory per the following procedure: To print records: press INTERCOM, dial # 076#, and press SPEAKER.
Page 78: Replacing The Software Cartridge
Digital Telephone System IMI66–107 2.15.3 Replacing The Software Cartridge Upgrading software in the digital telephone system consists of removing the current software cartridge and exchanging it with a board containing updated software. CAUTION To avoid any chance of electrostatic discharge damage to the softtware cartridge, avoid touching the connector with your fingers while handling it.
Page 79 IMI66–107 Digital Telephone System CAJS091A Typical Common Equipment Base Unit Software Cartridge (Lift out to remove) Figure 2–23: Removing The Software Cartridge CAJS091 Typical Common Equipment Base Unit Software Cartridge (Push in to install) Figure 2–24: Installing The Software Cartridge Installing The DSU 2 –...
Page 80: Master Clearing The System
Digital Telephone System IMI66–107 2.15.4 Master Clearing The System To reboot the system and load the new software, 1. Restore power to the system. 2. Perform the master clear procedure from the VDT or at the programming station as follows: •...
Page 81: 2.16 Checking The System Installation
IMI66–107 Digital Telephone System 2.16 Checking The System Installation The system operating features are set to default conditions at initial power-up. These conditions provide a basic operating system with a known set of parameters, and you should check out the system with the default conditions in place.
Page 82: Checking The General Operating Conditions
Digital Telephone System IMI66–107 2.16.3 Checking The General Operating Conditions 1. Check the red light emitting diode (LED) system status indicator. Be sure that it is on steady. If it is off or flashing, refer to the paragraph titled Checking the System Status Indicator. 2.
Page 83: 2.17 Isolating Failures
IMI66–107 Digital Telephone System 2.17 Isolating Failures Section 2.17 will help you to find and identify problems that might occur in the digital telephone system. 2.17.1 Checking The System Status Indicator A red LED located on the common equipment cabinet near the music port is the system status indicator.
Page 84: 2.18 Installing The System Options And Accessories
Digital Telephone System IMI66–107 2.18 Installing The System Options And Accessories This section contains information on installing the battery back up, the analog terminal interface, and the data interface unit. 2.18.1 Installing The Battery Back Up Assembly Preparing The Battery Back Up Assembly For Use The factory ships the battery back up assembly with the harness installed in the enclosure.
Page 85 IMI66–107 Digital Telephone System batt1.cdr Figure 2–26: Installing The Batteries Installing The DSU 2 – 55...
Page 86 Back Up Time (in hours) = 1 + [(0.1) (N)] K (Constant) = 0.9 for G0408 with or without a GM408 module 0.8 for G0816 with or without GM408 modules 0.8 for G1632 with or without GM408 modules 15 = ampere-hours...
Page 87 • With a fully-charged battery assembly connected to the common equipment, the measured voltage should be less than 13.8 VDC. If the voltage measures higher than this limit, contact your Comdial Technical Services representative. • The open output of the common equipment battery charger connection measures 13.6–13.8 VDC.
Page 88: Installing The Analog Terminal Interface
Digital Telephone System IMI66–107 2.18.2 Installing The Analog Terminal Interface Introducing The Analog Terminal Interface The ATI-D is a multipurpose, on-premise accessory for the digital telephone system. It has dual circuits that provide the following features: • INDUSTRY-STANDARD TELEPHONE (IST) INTERFACE—This feature adapts most industry-standard telephone (IST) devices to the digital telephone system.
Page 89 IMI66–107 Digital Telephone System Detailing The The Analog Terminal Interface Specifications Power requirements: Supplied by the common equipment Ringing voltage: 55 VAC Nominal @ 20 Hz (45 VAC minimum) Power rated to maximum REN = 2.0 Battery feed voltage: 24 VDC nominal Loop current limits between ATI-D and IST interface: 20 ma min.
Page 90 Digital Telephone System IMI66–107 Mounting The Analog Terminal Interface Refer to Section 2.1 at the beginning of this chapter for system mounting considerations that are also applicable to the analog terminal interface. Mounting Procedure 1. Unpack and carefully inspect the ATI-D for shipping damage. Notify the shipper immediately of any damage found.
Page 91 IMI66–107 Digital Telephone System Figure 2–28: Detailing The ATI-D Dimensions Installing The DSU 2 – 61...
Page 92 Digital Telephone System IMI66–107 Connecting The Analog Terminal Interface Connect the ATI-D per the diagram detailed on the following page. A grounding wire is not required for operation; however, one is desirable for decreasing radio frequency interference and electrostatic discharge susceptibility. The ATI-D housing provides a frame ground stud for this purpose.
Page 93 IMI66–107 Digital Telephone System Typical Station Connector Block Connect to Station Connector Jack CLIP TERMINALS Common Equipment Line Jack Jack Line Jack PIN 1 No Connection PIN 2 IST 2 (Tip) ATI-D PIN 3 IST 1 (Tip) PIN 4 IST 1 (Ring) PIN 5 IST 2 (Ring) PIN 6...
Page 94 Digital Telephone System IMI66–107 Installing An OPX Long Loop Adapter For Off-Premise Service As stated previously, the analog terminal interface is an on-premise device. You must use an OPX long loop adapter if you wish to adapt the ATI-D to support an off-premise application. An OPX long loop adapter connects to a single telephone line and can greatly extend the line’s loop length (the Proctor Model 46222 adapter*, for example, can extend line length to 30,000 feet).
Page 95 IMI66–107 Digital Telephone System Typical Station Connector Block Connect to station connector jack on common equipment. CLIP TERMINALS Common Equipment IST Jack Jack ATI-D Earth Ground (Optional) CAJS106 On-Premise IST Jack Long Loop Adapter 117 VAC Off-Premise IST Jack Figure 2–30: Installing The Long Loop Adapter Installing The DSU 2 –...
Page 96 Digital Telephone System IMI66–107 Understanding The Programming Requirements The ATI-D provides the interfacing capability required to connect most IST equipment to a station port of an digital telephone system. The IST provides basic intercom service coupled with the ability to access outside lines. Through programming, the IST acts as either as an intercom-only telephone or as a full-featured business telephone.
Page 97 IMI66–107 Digital Telephone System ATI-D Distinctive Ringing Intercom calls that ring at equipment connected through an ATI-D have a different cadence than outside calls. Intercom ring cadence is: 1 sec. on, .5 sec. off, 1 sec. on, 3.5 sec. off. Outside call ring cadence is: 2 sec.
Page 98: Installing The Data Interface Unit
Digital Telephone System IMI66–107 2.18.3 Installing The Data Interface Unit Unpack the Data Interface Unit (DIU) and check for the following parts: • Telephone line cord • Power cable with attached transformer. Verify that the Digital Service Unit (DSU) contains software revision 17A or later. If you need to upgrade the DSU software, see the section entitled “Software Cartridge.”...
Page 99 IMI66–107 Digital Telephone System 3. Install two #8 X 3/4-inch screws in the wall at the locations you marked in step 2. Tighten the screws until the screw heads are 1/4-inch from the surface of the wall. 4. Place the DIU on the wall with the screw heads inserted into the slots provided on the bottom surface of the DIU.
Page 100 Digital Telephone System IMI66–107 Making The Cable Connections Four cable connections are required to the DIU—station line cord, digital telephone line cord, IST/FAX/MODEM line cord, and power cable. 1. Disconnect the line cord on the digital telephone from the digital station port connector and plug it into the connector labeled PHONE on the DIU.
Page 101 IMI66–107 Digital Telephone System To KSU Station Port Typical Multiline Digital Telephone Impact Model 8012S Illustrated) FFigure 2–33: Making The Cable Connections Installing The DSU 2 – 71...
Page 102: 2.19 Supporting Caller Identification Service
G1632, connect its modular plug to RS232 Data Port B on the cabinet. If you connect it to a G0816 or a G0408, you must remove the cable’s modular plug to provide individual RD and SG leads that you can punch down at terminals 42 and 44 of the J1 station connector block.
Page 103 IMI66–107 Digital Telephone System Lines 1-8 CID08 Unit #1 RS-232 In RS-232 Out Lines 9-16 CID08 Unit #2 RS-232 B Serial Data Port RS-232 In RS-232 Out Lines 17-24 CID08 Unit #3 RS-232 In RS-232 Out To RS-232 B (Pin 5) SG CTS (Pin 2) Serial Data Port (Pin 4) TD...
Page 104: Setting The Caller Id Parameter Switches
Digital Telephone System IMI66–107 2.19.1 Setting The Caller ID Parameter Switches The Caller ID device has two banks of parameter switches located on its front panel. You must set the switches of the S2 switch band in a certain manner to enable Caller ID operation. Switches S2–1 through S2–5 set the baud rate, data bits, and parity, while switches S2–6, S2–7, and S2–8 set the unit address for each device.
Page 105 IMI66–107 Digital Telephone System Power LED Data LED PWR DATA Caller ID CAJS092 Dip Switch 2 (Switches 1-8) Dip Switch 1 (Switches 1-8) Figure 2–37: Dip Switch Locations On The Caller ID Unit Installing The DSU 2 – 75...
Page 106: 2.20 Supporting The Tracker Paging System
Digital Telephone System IMI66–107 2.20 Supporting The Tracker Paging System The optional Tracker paging system allows you to send alpha/numeric or numeric-only messages to the Tracker Pagers assigned to a station extension number. The type of message that the system delivers is dependent on the Tracker Pager model being used. Tracker’s paging option requires only one connection to the digital telephone system;...
Page 107 IMI66–107 Digital Telephone System G. Press CONTROL C for main menu, and logout from the programming mode. 2. Disconnect the VDT from data port A. —At this time, the system begins polling data port A every two seconds and waiting for a response from the Tracker base station.
Page 108: 2.21 Supporting Dva Operation
Digital Telephone System IMI66–107 2.21 Supporting DVA Operation Digital voice announcing uses a hardware peripheral device (product code DVA01) connected to a digital station port to play pre-recorded announcements and messages during an in-progress call. The DVA stores the pre-recorded messages in its memory for recall when needed. The DVA derives its operating power from the common equipment cabinet’s digital station port;...
Page 109 IMI66–107 Digital Telephone System DVA003 Station Jack Pin-Out Typical Station Pin 1 No Connection Connector Block Pin 2 No Connection Pin 3 Tip 1 Pin 4 Ring 1 Pin 5 No Connection Pin 6 No Connection 25-Pair Male To STATION TAPE IN DVA01 Female...
Page 110: 2.22 Fcc Rules And Regulations
Digital Telephone System IMI66–107 2.22 FCC Rules And Regulations This electronic key system complies with Federal Communications Commission (FCC) Rules, Part 68. The FCC registration label on the common equipment cabinet contains the FCC registration number, the ringer equivalence number, the model number, and the serial number or production date of the system. Notifying The Telephone Company Unless a telephone operating company provides and installs the system, the telephone operating company which provides the lines must be notified before a connection is made to them.
Page 111 IMI66–107 Digital Telephone System Recognizing Radio Frequency Interference The electronic key system contains incidental radio frequency generating circuitry and, if not installed and used properly, may cause interference to radio and television reception. This equipment has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of Part 15 of FCC Rules.
Page 113 IMI66–107 Digital Telephone System Programming The System Section Title ......................Page Using Chapter Three .................3–7 Understanding System Programming............3–7 3.2.1 Using A Telephone To Program The System.........3–7 3.2.2 Supporting DigiTech Telephones (Revision I And Later) ....3–8 3.2.3 Converting Button Designations ............3–9 3.2.4 Using A VDT To Program The System ..........3–11 3.2.5...
Page 114 Digital Telephone System IMI66–107 Section Title ..................Page 3.4.13 Tone or Voice Signaling...............3–30 3.4.14 Inhibiting System Features ..............3–31 System Timing ..................3–32 3.5.1 Call Park Recall Time................3–32 3.5.2 Extended DTMF Tones For Automatic Dialing........3–33 3.5.3 Pause Time ...................3–34 3.5.4 Recall/Flash ..................3–34 3.5.5 Timed Hold Recall................3–35 3.5.6 Unanswered Call Transfer Recall Time ..........3–36...
Page 115 IMI66–107 Digital Telephone System Section Title ......................Page 3.7.14 Group Call Pickup ................3–62 3.7.15 Handset Volume Control On Impact Telephones........ 3–63 3.7.16 Headset Interface ..................3–64 3.7.17 Interactive Buttons................3–65 3.7.18 Idle Line Preference................3–66 3.7.19 Personal Ringing Tones................3–67 3.7.20 Prime Line, Prime Group, And Prime Intercom........3–68 3.7.21 Message Wait Originate ...............3–68 3.7.22...
Page 116 Digital Telephone System IMI66–107 Section Title ......................Page Account Codes ..................3–88 3.9.1 Account Code Length ................3–88 3.9.2 Account Code List ................3–89 3.9.3 Enabled or Disabled Account Codes ............3–90 3.9.4 Forced or Optional Entry Account Codes ..........3–90 3.9.5 Message Display Time For Account Codes .........3–92 3.9.6 Verified Account Code Entry ...............3–93 3.10 The Analog Terminal Interface ..............3–94...
Page 117 IMI66–107 Digital Telephone System Section Title ......................Page 3.15 Versatile Voice Processing..............3–113 3.15.1 Using Tracker Paging System With Versatile Voice Processing ..3–113 3.15.2 Using Tracker For Message Notification ...........3–114 3.15.3 Transferring Callers To Voice Mail ...........3–114 3.15.4 Auto Station Logon ................3–114 3.15.5 Visual Voice Mail Support ..............3–115 3.16 Integrated Call Costing .................3–116...
Page 118 Digital Telephone System IMI66–107 Section Title ......................Page 3.19 Toll Restriction Tables................3–147 3.19.1 Assign Entries To Toll Restriction Tables .........3–148 3.19.2 Programming Toll Restriction Table Entries........3–149 3.19.3 Assign Toll Restriction Tables To Lines ..........3–150 3.19.4 Assign Toll Restriction Tables To Stations ........3–150 3.19.5 Assign Toll Restriction Tables To Stations For Night Transfer (of ringing) ............3–151...
Page 119: Using Chapter Three
IMI66–107 Digital Telephone System Using Chapter Three Since Chapter 3 deals only with the programming of the system, each programming step includes only a brief explanation of that feature. Therefore, before you begin programming the system, familiarize yourself with all of the system’s features that are discussed in Appendix A. By doing so, you can be certain that you are programming what the customer wants.
Page 120: Supporting Digitech Telephones (Revision I And Later)
Digital Telephone System IMI66–107 3.2.2 Supporting DigiTech Telephones (Revision I And Later) There are several items that you need to consider when connecting revision I and later DigiTech telephones to the digital telephone system: • While the system software cartridge (product code Snnnn) with software release 11A and later supports the use of all DigiTech telephones regardless of their revision letter, any systems with a software release of 9 or earlier will not support the revision I and later telephones.
Page 121: Converting Button Designations
IMI66–107 Digital Telephone System 3.2.3 Converting Button Designations When you first power a new system with no telephones connected, it defaults its station ports as follows: Software Type Telephone Type Snnnn DigiTech 24-line telephones Innnn Impact 24-line speakerphones When you connect a telephone to a powered-up system or when you turn on the AC power to a system after you have connected a telephone to it, the system automatically button maps the telephone according to the type of software cartridge the system has.
Page 122 Digital Telephone System IMI66–107 When you perform class of service programming from stations 10 or 12 and you have placed an Impact telephone at the programming port, you should place the programming overlay on it. This makes the button designations match the A and B designations called for in this system programming manual.
Page 123: Using A Vdt To Program The System
IMI66–107 Digital Telephone System 3.2.4 Using A VDT To Program The System You can perform programming using a customer-provided Video Display Terminal (VDT) with an RS-232 compatible, serial interface. VDT programming is completely menu driven and easy to follow. It is arranged somewhat differently from station port programming categories to facilitate menu usage.
Page 124: Master Clearing The System
Digital Telephone System IMI66–107 3.2.6 Master Clearing The System After you have completely installed a telephone system for the first time or if a system that you previously installed has been turned off and placed out of service for a period of time (several weeks, for example), perform a master clear programming procedure before placing it into service.
Page 125: Master Clearing And Defaulting The System
IMI66–107 Digital Telephone System Master Clearing and Defaulting The System You can return the entire programming configuration to the factory settings using the master clear procedure. You can also return the individual system, line, and station class of service configurations to their factory settings using the system, line, and station default procedures.
Page 126: Defaulting The Stations
Digital Telephone System IMI66–107 3.3.4 Defaulting The Stations Description: Returns the station configuration features to factory settings. To Program: 1. Press INTERCOM, dial # 7 4 6 . “CONFIG. MODE” 2. Dial 50. “STATION DEFAULT” 3. Dial 00 to default station ports system-wide —OR—...
Page 127: Programming Password Protection
NOTE: Password protection programming is a Video Display Terminal feature only. You can not customize a password using station 10 programming entry. *Please contact Comdial Technical Service for details. System Programming 3 – 15...
Page 128 Digital Telephone System IMI66–107 To Program: 1. From keyboard, type I 746 for the programming mode. 2. From main COS programming menu, —type 6 to change installer password —OR— —type 7 to change administrator password and press RETURN. 3. At menu prompt, type customized password using any six alpha-numeric or numeric only characters.
Page 129: System Features
IMI66–107 Digital Telephone System System Features Configuring the system means that you are setting the parameters that will be true system-wide. You should make a record in Chapter 4 of all programming decisions that you make—it will help you keep track of what you have done and will help you troubleshoot any problem that might arise later.
Page 130: Data Baud Rate
Digital Telephone System IMI66–107 3.4.2 Data Baud Rate Description: The speed or baud rate of the data bit stream, which carries the SMDR and configuration data between the system and an external data device, must be programmed to match the requirements of the data device.
Page 131: Do Not Disturb (Dnd)
IMI66–107 Digital Telephone System 3.4.3 Do Not Disturb (DND) All of the following features are part of the Do Not Disturb (DND) application. Do Not Disturb Button Description: A telephone user can press a button (either one that you have mapped on that station or one that is provided by an interactive button on an LCD speakerphone) to set the station to a DND condition.
Page 132: Exclusive Hold
Digital Telephone System IMI66–107 Do Not Disturb Override Capability Description: A caller to a DND station can override a DND condition when you program the calling station to have the DND override feature. To Program: 1. Dial 53. “STATION FEATURES” 2.
Page 133: Lcd Messaging
IMI66–107 Digital Telephone System 3.4.6 LCD Messaging Description: You can create messages that telephone users can set at their stations to be displayed by any LCD speakerphone that calls them on the intercom line. The system provides two standard messages but you can use this programming procedure to create up to 10 custom messages.
Page 134 Digital Telephone System IMI66–107 Table 3–2: Character Code Table Character Code Character Code Character Code Space “ 3 – 22 System Programming...
Page 135: Pa Port Options
IMI66–107 Digital Telephone System 3.4.7 PA Port Options The common equipment includes a special paging port that you can use to couple the system to a customer-supplied external paging amplifier. The following section details the programming features for the paging port. Ringing Type Description: You can assign lines to the PA port for direct ring, delayed ring, or night transfer (of...
Page 136 Digital Telephone System IMI66–107 Ringing Relay Tracking Description: You can select the tracking source for the ringing relay to be either station 17 ringing or the ringing that you have assigned to the paging port. Making it track the ringing that you have assigned to the PA port provides relay control for the customer-supplied PA amplifier if needed.
Page 137: Station Monitoring
IMI66–107 Digital Telephone System 3.4.8 Station Monitoring You can enable two types of station monitoring: visual ring indication and audible monitoring. Visual Ring Indication Description: The DSS/BLF at a station provides idle, busy, and ringing status of all of the monitored stations.
Page 138: System Alarm Reporting
Digital Telephone System IMI66–107 3.4.9 System Alarm Reporting The system can send special codes that convey certain system alarm conditions to selected stations where they will show on their LCD displays. System Alarm Report Enabling Description: Enable the system alarm reporting on a system-wide basis using this feature. To Program: 1.
Page 139: System Clock
IMI66–107 Digital Telephone System 3.4.10 System Clock Description: The system clock maintains current date and time information. The system provides this information to LCD speakerphones for display. Set the system time with this feature. The system attendant also has access to this feature. To Program: 1.
Page 140: System Speed Dial
Digital Telephone System IMI66–107 3.4.11 System Speed Dial Description: The system speed dial is a system-wide list of numbers that all users can access for automatic dialing. Those users with two-line display LCD speakerphones can scroll through the list of names that you assign to the system speed dial numbers using their speakerphone’s display.
Page 141 IMI66–107 Digital Telephone System Lower Case Character Chart Upper Case Character Chart Character Code Character Code Symbol And Number Character Chart Character Code SPACE “ System Programming 3 – 29...
Page 142: Tandem Attendant
Digital Telephone System IMI66–107 3.4.12 Tandem Attendant Description: When you enable this feature, a recall from an unanswered call transfer or timed hold recall will ring at both attendant stations. When you disable it, only the attendant station that transferred the call will ring. To Program: 1.
Page 143: Inhibiting System Features
IMI66–107 Digital Telephone System 3.4.14 Inhibiting System Features Description: You can disable certain features system-wide to prevent unauthorized users from tampering with the system. You can performing the system default procedure to re-enable features that you disable with this feature inhibit procedure. To Program: 1.
Page 144: System Timing
Digital Telephone System IMI66–107 System Timing The digital telephone system has several attributes that control timing dimensions of system operation. The following features set these various timing attributes. 3.5.1 Call Park Recall Time Description: A call that remains in a parking orbit for a programmed length of time automatically returns to a timed hold recall condition at the parking station.
Page 145: Extended Dtmf Tones For Automatic Dialing
IMI66–107 Digital Telephone System 3.5.2 Extended DTMF Tones For Automatic Dialing Description: When a telephone user dials a number automatically (autodial, saved number redial, etc), the duration of the generated DTMF tones are as you set them with this programming option.
Page 146: Pause Time
Digital Telephone System IMI66–107 3.5.3 Pause Time Description: During auto dials and speed dials, it is sometimes necessary to delay the sending of digits to give switching equipment time to prepare for receiving them. A pause is stored for this purpose whenever the user presses the HOLD button.
Page 147: Timed Hold Recall
IMI66–107 Digital Telephone System 3.5.5 Timed Hold Recall Description: After a call has been on hold for a programmed length of time, the system will recall the station that placed the call on hold. Set the hold recall time with this programming procedure.
Page 148: Unanswered Call Transfer Recall Time
Digital Telephone System IMI66–107 3.5.6 Unanswered Call Transfer Recall Time Description: A transferred call that remains unanswered after a programmed length of time will return to the transferring station for answering. Set the transfer recall time with this programming procedure. To Program: 1.
Page 149: Line Programming
IMI66–107 Digital Telephone System Line Programming By using line configuration, you can program the parameters for individual lines. The programming decisions you make for a particular line will only be true for that line and not for the entire telephone system.
Page 150: Automatic Privacy
Digital Telephone System IMI66–107 3.6.2 Automatic Privacy You can make a line private or non-private. In the private mode, a station has exclusive use of a line during a call. Lines are private unless you re-program them and make them non-private. Private Or Non-Private Lines Description: Use this programming feature to set which lines are private or non-private.
Page 151: Line Disable
IMI66–107 Digital Telephone System 3.6.3 Line Disable Description: You can take a line port out of service when necessary (because of defect or some other reason) using this programming procedure. To Program: 1. Dial 31. “DISABLE LINES” 2. Select line ports to be disabled. —Line port 1–14 = Dial 01–14 or Press A1–A14 —Line port 15, 16 = Dial 15, 16 or press B1, B2 —Line port 17–24 = Dial 17–...
Page 152: Line Names
Digital Telephone System IMI66–107 3.6.5 Line Names Description: You can name lines as to their function to identify them for use. Names such as WATTS, CO, etc., when appearing on the LCD speakerphone displays, make locating a desired line easier for the station user to do. A line name can contain up to five characters. See the chart on the following page for the line-name characters.
Page 153 IMI66–107 Digital Telephone System Table 3–4: Character Code Table Character Code Character Code Character Code Space “ System Programming 3 – 41...
Page 154: Line Port Functions
Digital Telephone System IMI66–107 3.6.6 Line Port Functions You can set individual line ports to function as auxiliary line ports, for a paging amplifier, for example, or to function with standard CO lines. Auxiliary Lines Description: You can condition a line port to serve as a port for an external paging amplifier. To program: 1.
Page 155: Line To Line Port Re-Assignment
IMI66–107 Digital Telephone System 3.6.7 Line To Line Port Re-Assignment Description: You can reassign the programming attributes for a line that the installer has connected to a particular line port to a different line port with this programming action. This feature allows you to automatically exchange all software attributes for one line with those assigned to another at a different line port without physically re-locating the lines or reprogramming any of the attributes.
Page 156: Pulse/Tone Switchable
Digital Telephone System IMI66–107 3.6.8 Pulse/Tone Switchable You can configure individual lines to have tone dialing or pulse dialing at default. Pulse Dialing Description: If the installer has connected rotary dial lines to the system, you must condition those line ports as pulse dial ports.
Page 157: Block Programming
IMI66–107 Digital Telephone System 3.6.9 Block Programming Description: You can use this configuration procedure to assign those features that you have assigned to any one line (using the procedures detailed on the previous pages) to any other line or to an entire block of lines. To Program: Line Button Method 1.
Page 158: Positive Disconnect Supervision
Digital Telephone System IMI66–107 3.6.10 Positive Disconnect Supervision Description: When a station is on line with an outside caller and the caller hangs up, the CO may send a positive disconnect signal to the DSU. You can enable the positive disconnect supervision feature on a per-line basis.
Page 159: Station Features
IMI66–107 Digital Telephone System Station Features Station programming means that you are programming the functions for one particular station, or port. While it isn’t necessary, it is a good idea to do station programming after you have done system and line programming.
Page 160: Access Denied
Digital Telephone System IMI66–107 3.7.1 Access Denied Description: You can deny access to certain lines at certain stations. When you do this, a station user cannot select a denied line. To Program: 1. Dial 54. “STA/LINE CONFIG.” 2. Dial 5. “ACCESS DENY”...
Page 161: All-Call And Zone Paging
IMI66–107 Digital Telephone System 3.7.2 All-Call and Zone Paging You can program the system so that the users can make announcements to stations located in certain areas of the site or to all of the stations. Similarly, you can program a station with one-button access to the paging feature.
Page 162 Digital Telephone System IMI66–107 Assign All-Call and Zone Paging Button Description: If you wish, you can assign a paging button to provide a station with one-button access to the all-call and zone paging feature. To Program: 1. Dial 56. “BUTTON MAPPING ” 2.
Page 163: Audible Monitoring
IMI66–107 Digital Telephone System 3.7.3 Audible Monitoring The DSS/BLF at a multiline station provides a visual indication of idle, busy, and ringing status of the monitored stations. You can also provide audible indication of direct and delayed ringing for selected stations;...
Page 164: Automatic Hold
Digital Telephone System IMI66–107 3.7.4 Automatic Hold You can give station users the ability to place an existing line or intercom call on hold when she or he presses another line button. Automatic Hold With Line Calls Description: When you enable this feature, the telephone user can automatically place an existing line call on hold when she or he presses another line button to answer a second call.
Page 165: Automatic Privacy
IMI66–107 Digital Telephone System 3.7.5 Automatic Privacy You can make a line private or non-private. In the private mode, a station has exclusive use of a line during a call. You can arrange for individual stations to automatically release privacy while on private lines.
Page 166: Call Forward On Busy/Ring-No Answer
Digital Telephone System IMI66–107 3.7.6 Call Forward On Busy/Ring–No Answer The system can automatically forward busy and ring-no answer calls to a new station. The system sends these calls to any idle station associated either by intercom hunt group or by department with the called station.
Page 167 IMI66–107 Digital Telephone System Intercom Hunt Group Description: You can link stations together to form intercom hunt groups. Calls to a busy station in a hunt group will search the group for an idle station to ring. To Program: 1. Dial 53. “STATION FEATURES”...
Page 168: Call Origination Denied
Digital Telephone System IMI66–107 3.7.7 Call Origination Denied Description: You can deny users of selected stations the ability to originate calls on specified lines. This feature does not prevent the user from answering incoming calls on these lines. To Program: 1. Dial 54. “STA/LINE CONFIG.”...
Page 169: Data Security Port
IMI66–107 Digital Telephone System 3.7.9 Data Security Port Description: While port is active on a call, this feature prevents any incoming tones associated with other system features from interrupting the call. To Program: 1. Dial 53. “STATION FEATURES” 2. Dial 26. “DATA SECURE PORT”...
Page 170: Executive Override
Digital Telephone System IMI66–107 3.7.11 Executive Override Description: You can provide selected stations with busy override. This feature allows the station to override a busy condition at a station, sound a warning tone, and gain access to the existing conversation. To Program: 1.
Page 171: Flexible Ringing Assignments
IMI66–107 Digital Telephone System 3.7.12 Flexible Ringing Assignments You can enable different ringing assignments for individual lines and stations. Direct/Delayed Ringing Description: You must program ringing assignments on a per station/per line basis. You can control ringing for every line that has appearance at a station assigning immediate, or direct, ringing to some lines and delayed ringing to others.
Page 172: Night Transfer (Of Ringing)—Operation
Digital Telephone System IMI66–107 Night Transfer (Of Ringing)—Line/Station Assignments Description: You or the system attendant can place the system into the night transfer (of ringing) mode of operation. While in this mode of operation, the system will activate special line/station ringing assignments.
Page 173: Delayed Ringing Times
IMI66–107 Digital Telephone System Delayed Ringing Times Description: You assign delayed ringing to stations for specific lines, you can also set the time length of the delay. To Program: 1. Dial 17. “SYSTEM FEATURES ” 2. Dial 05. “DELAY RING XX” 3.
Page 174: Flexible Station Numbering
Digital Telephone System IMI66–107 3.7.13 Flexible Station Numbering Description: The system supports a flexible station numbering plan for calling individual stations and departments. You can program each station port to respond to the dialing of any available number between 10 and 7999; however, the system will not allow you to assign the same dialing code as both a station extension number and a department access code, nor will the system allow you to assign an extension number or access code conflict such as 15 and 1500.
Page 175: Handset Volume Control On Impact Telephones
IMI66–107 Digital Telephone System 3.7.15 Handset Volume Control On Impact Telephones Description: Impact telephones have 8 handset volume settings at default. You may increase the number of volume settings to 13 on an individual station basis. To Program: 1. Dial 53. “STATION FEATURES”...
Page 176: Headset Interface
Digital Telephone System IMI66–107 3.7.16 Headset Interface You can program LCD speakerphones equipped with the optional headset jack to use a headset as well as the handset or speakerphone. NOTE: The system delivers subdued off-hook voice announcements (SOHVA) to the headset. Because a headset exhibits a coupling effect between the earpiece and microphone, it may allow the outside party to hear a SOHVA message.
Page 177: Interactive Buttons
Description: The digital telephone system supports the operation of interactive buttons on all currently produced Comdial proprietary LCD speakerphones. Interactive buttons provide users with quick, easy access to system features and an expanded display that prompts them on feature operation and progress. DigiTech and Impact LCD speakerphones provide interactive buttons to the user at all times;...
Page 178: Idle Line Preference
Digital Telephone System IMI66–107 3.7.18 Idle Line Preference Description: When you enable idle line preference, a station will automatically connect to any assigned and idle line that you have programmed for this purpose when the user takes the station off hook. To Program: 1.
Page 179: Personal Ringing Tones
IMI66–107 Digital Telephone System 3.7.19 Personal Ringing Tones Description: You can program stations to ring in one of six distinctive tones: 1. 666/571 Hz @ 16 Hz warble 2. 1000/800 Hz @ 16 Hz warble 3. 666/571 Hz @ 23 Hz warble 4.
Page 180: Prime Line, Prime Group, And Prime Intercom
Digital Telephone System IMI66–107 3.7.20 Prime Line, Prime Group, And Prime Intercom Description: If you assign a group of lines, an intercom line, or one individual line to a particular station for use as its prime line, the station automatically selects it for use when the user takes it off-hook.
Page 181: Ringing Line Preference
IMI66–107 Digital Telephone System 3.7.22 Ringing Line Preference Description: When you assign this feature to a station, it will automatically answer a ringing line when its user takes it off-hook. To Program: 1. Dial 53. “STATION FEATURES” 2. Dial 09. “RING LINE PREF.”...
Page 182 Digital Telephone System IMI66–107 SOHVA Groups Description: Use this procedure to arrange station ports to originate and/or receive SOHVA calls by assigning SOHVA calling groups to them. Also provide selective SOHVA calling to the system by arranging certain station ports together into groups for SOHVA calling between one another while excluding other station ports in the system.
Page 183 IMI66–107 Digital Telephone System Table 3–6: Fixed SOHVA Groups SHOVA Group Group Configurations Group 1 Receive From Originate To Group 2 Receive From Originate To Group 3 Receive From Originate To Group 4 Receive From Originate To Group 5 Receive From Originate To Group 6 Receive From...
Page 184: Sohva Tone Burst Quantities
Digital Telephone System IMI66–107 SOHVA Tone Burst Quantities Description: Use this procedure to set the number of SOHVA tone bursts that sounds at the system stations. You can choose from one to six tone bursts, and the choice that you make here affects all stations that receive SOHVA calls.
Page 185: Service Observing
IMI66–107 Digital Telephone System 3.7.24 Service Observing You can give selected stations the capability to monitor, in an un-announced manner, an active call at another station. Assign Service Observing Description: Select stations to have the service observe feature using this programming. NOTE: Since this feature requires the executive override feature to function, the system automatically enables that feature for the station when you enable...
Page 186: Station Disable
Digital Telephone System IMI66–107 3.7.25 Station Disable Description: You can disable station ports on a per station basis. To Program: 1. Dial 59. “DISABLE STATIONS” 2. Select station ports to be disabled (LED On = Disabled) —Station 10–57: Dial 10–57 or press C10–C57. 3.
Page 187 IMI66–107 Digital Telephone System Table 3–7: Character Code Table Character Code Character Code Character Code Space “ System Programming 3 – 75...
Page 188: Station To Station Port Reassignment
Digital Telephone System IMI66–107 3.7.27 Station To Station Port Reassignment Description: Use this procedure to reassign the programming attributes for a station connected to a particular station port to a different station port (logical to physical reassignment). This feature allows you to automatically exchange all software attributes for a station (logical assignment) connected at one station port with those attributes assigned to another station at a different station port without physically relocating the stations (physical assignment) or reprogramming any of the attributes.
Page 189: System Alarm Report Stations
IMI66–107 Digital Telephone System 3.7.28 System Alarm Report Stations You can program the system to report any system alarms to designated stations. Enable Alarm Reporting Description: If you arrange the system to report alarms, also use this programming feature to enable stations to display alarm reports after the station user takes appropriate action.
Page 190: Voice Announce Blocking
Digital Telephone System IMI66–107 3.7.29 Voice Announce Blocking Description: This feature allows a station user to block voice-signaled intercom calls. To Program: 1. Dial 53. “STATION FEATURES” 2. Dial 04. “VOICE BLOCK” 3. Select station ports (LED On = Selected). —Station 10–57 = Dial 10–57 or press C10-C57.
Page 191: Button Mapping The Stations (Non-Square Configuration)
IMI66–107 Digital Telephone System Button Mapping The Stations (Non-Square System Configuration) You can assign (map) every programmable button at each digital station to be line-select buttons so that they provide access to outside lines; to be direct station select (DSS) buttons so that they provide quick access to system stations;...
Page 192 Digital Telephone System IMI66–107 3 – 80 System Programming...
Page 193: Account Code Button
IMI66–107 Digital Telephone System 3.8.1 Account Code Button Description: Press the account code button and then dial an account code to record a call into a particular category without interrupting the call. To Program: 1. Dial 56. “BUTTON MAPPING” 2. Dial 17. “ASSIGN ACCT KEY ”...
Page 194: Automatic Call-Back Button
Digital Telephone System IMI66–107 3.8.2 Automatic Call-Back Button Description: When a user presses this button after they encounter a busy tone, the system will automatically ring both the called station and the user’s station when the called station becomes idle. To Program: 1.
Page 195: Call Forward Button
IMI66–107 Digital Telephone System 3.8.4 Call Forward Button Description: This button provides one-button forwarding of all calls to another extension. To Program: 1. Dial 56. “BUTTON MAPPING” 2. Dial 11. “ASSIGN CALL FWD ” 3. Select button to be programmed —Press A1–A14, B1–B10.
Page 196: Do Not Disturb (Dnd) Button
Digital Telephone System IMI66–107 3.8.6 Do Not Disturb (DND) Button Description: Pressing the DND button prevents other stations from calling the DND station. To Program: 1. Dial 56. “BUTTON MAPPING” 2. Dial 07. “ASSIGN DND CODE” 3. Select button to be programmed —Press A1–A14, B1–B10.
Page 197: Line Button
IMI66–107 Digital Telephone System 3.8.8 Line Button Description: Line select buttons provide access to outside lines. To Program: 1. Dial 56. “BUTTON MAPPING” 2. Dial 02. “ASSIGN LINE” 3. Select button to be programmed: —Press A1–A14, B1–B10. 4. Select line ports to be assigned. —Line port 1–14 = Dial 01–14 or Press A1–A14 —Line port 15, 16 = Dial 15–16 or Press B1, B2 —Line port 17–24 = Dial 17–24 or press HOLD then press A1–A8.
Page 198: Line Group Queue Button
Digital Telephone System IMI66–107 3.8.10 Line Group Queue Button Description: A station user can queue for a busy line by pressing a line group queue button. To Program: 1. Dial 56. “BUTTON MAPPING ” 2. Dial 15. “ASSIGN LINE GRP Q” 3.
Page 199: Privacy Button
IMI66–107 Digital Telephone System 3.8.12 Privacy Button Description: A user engaged in a private call can press the privacy button to change a current call into a non-private one. To Program: 1. Dial 56. “BUTTON MAPPING ” 2. Dial 06. “ASSIGN PRIVACY ”...
Page 200: Voice Announce Block Button
Digital Telephone System IMI66–107 3.8.14 Voice Announce Block Button Description: Telephone users can block voice announced intercom calls and station paging by pressing this button. To Program: 1. Dial 56. “BUTTON MAPPING ” 2. Dial 14. “ASSIGN V. A. B.” 3.
Page 201: Account Codes
IMI66–107 Digital Telephone System Length For Entered Account Codes Description: This feature defines the number of account code digits that a user must enter before the system will accept the code. Account code length can range from 3 to 16 digits; however, its length must always be equal to or greater than the current verified account code length.
Page 202: Enabled Or Disabled Account Codes
Digital Telephone System IMI66–107 3.9.3 Enabled or Disabled Account Codes Description: Use this procedure to enable or disable the account code feature for the system. To Program: 1. Dial 75. “SMDA PROGRAMMING” 2. Dial 07. “XXXXXXXX ACCOUNT” 3. Press A1 to toggle the feature on or off (LED On = Enabled). —OR—...
Page 203 IMI66–107 Digital Telephone System Forced Account Code Emergency Numbers Description: Even if you arrange for the system to force account code entries, users can always dial emergency numbers without first entering an account code. Use this programming feature to enter up to 10 emergency numbers. Each number can be a minimum of 1 digit and a maximum of 12 digits.
Page 204: Message Display Time For Account Codes
Digital Telephone System IMI66–107 3.9.5 Message Display Time For Account Codes Description: When you enable the account code feature, LCD speakerphones prompt users to enter an account code with a displayed message that the system clears at the end of a programmable display time.
Page 205: Verified Account Code Entry
IMI66–107 Digital Telephone System 3.9.6 Verified Account Code Entry Description: Use this programming procedure to arrange for the system to either verify or not verify the account codes that users enter. To Program: 1. Dial 75. “SMDA PROGRAMMING”. 2. Dial 08. “VERIFICATION XXX.
Page 206: The Analog Terminal Interface
Digital Telephone System IMI66–107 3.10 The Analog Terminal Interface The Analog Terminal Interface device (ATI-D) is a multipurpose on-premise accessory for the digital telephone system. It has dual circuits that allow external analog telephony equipment, such as a voice mail system, an industry-standard model 2500 tone dial telephone, a model 500 rotary dial telephone, etc., to interface with two digital station ports.
Page 207: Ati Distinctive Ringing
IMI66–107 Digital Telephone System 3.10.1 ATI Distinctive Ringing Description: Intercom calls that ring at equipment connected through an ATI-D have a different cadence than outside calls have. Intercom ring cadence is: 1 sec. on, 0.5 sec. off, 1 sec. on, 3.5 sec. off. Outside call ring cadence is: 2 sec. on, 4 sec. off. If needed, you can disable this distinctive ringing feature to make the intercom ring cadence the same as that for outside calls.
Page 208: Direct Department Calling
Digital Telephone System IMI66–107 3.11 Direct Department Calling Direct department calling allows the system to assign lines to one of four different departments. Calls received on department lines and calls that are transferred to a department from within the system search for an idle station in that department.
Page 209: Access Codes For Direct Department Calling
IMI66–107 Digital Telephone System 3.11.1 Access Codes For Direct Department Calling Description: You can program department access codes to be any number between 10 and 7999; however, the system will not allow you to assign the same dialing code as both a station extension number and a department access code;...
Page 210: Station Ports For Direct Department Calling
Digital Telephone System IMI66–107 3.11.3 Station Ports For Direct Department Calling Description: You can group stations by department to allow a call to search for an idle station within a department. This search occurs when a busy or RNA is encountered at a called department station.
Page 211: Unanswered Call Transfer Recall Time For Direct Department Calling
IMI66–107 Digital Telephone System 3.11.4 Unanswered Call Transfer Recall Time For Direct Department Calling Description: A transferred call that remains unanswered in a department after a programmed length of time will return to the transferring station for answering. Set the department transfer recall time with this programming procedure.
Page 212: Call Forward On Busy/Ring-No Answer
Digital Telephone System IMI66–107 3.11.5 Call Forward on Busy/Ring—No Answer The system can automatically forward busy and ring-no answer calls to a new station. The system sends these calls to any idle station associated either by intercom hunt group or by department with the called station.
Page 213: Direct Inward Station Dialing
IMI66–107 Digital Telephone System 3.12 Direct Inward Station Dialing (DISD) The DISD feature allows an external party to call an intercom station directly without assistance by the attendant. The system must receive the DISD call on a line that you have programmed to allow this feature.
Page 214: Dial Time Limit
Digital Telephone System IMI66–107 3.12.1 Dial Time Limit Description: When a caller does not complete extension number dialing within the programmed dial time limit, the system routes a DISD call to the assist station if you have programmed one; otherwise, it drops the line. To Program: 1.
Page 215: Disd Assist Station
IMI66–107 Digital Telephone System 3.12.3 DISD Assist Station Description: When a caller does not complete extension number dialing within the programmed dial time limit, the system routes the call to the DISD assist station. To Program: 1. Dial 46. “DISD ASSIST” 2.
Page 216: Disd Incoming Rings
Digital Telephone System IMI66–107 3.12.4 DISD Incoming Rings Description: The number of rings that occur on a DISD line before it is answered is programmable. Setting a large number of rings allows time for a call to be serviced in a regular manner by stations that have line appearance for the DISD line if such action is desired.
Page 217: Data Printer Service
IMI66–107 Digital Telephone System 3.13 Data Printer Service When you connect a data printer to the system, the system automatically prints the station message detail record (SMDR) for the entire system without any programming or user intervention. You call also command the data printer to print partial or complete printouts of the configuration data for the system.
Page 218: Voice Mail Interface
NOTE: Some features only apply to specific Comdial voice mail systems (e.g. Execumail, V.V.P.). If you are using a different voicemail system, you may have to perform additional programming steps to make these features operational.
Page 219: Voice Mail Port
The assign voice mail port programming procedure only applies to voice mail systems supported by Comdial’s proprietary DTMF integration. Once you perform this step, the station port will only emit DTMF tones (it will not emit INTERCOM tones or ring-back tones).
Page 220 Digital Telephone System IMI66–107 Assign Ringing For Automatic Attendant Operation Description: With its automatic attendant feature, the voice mail system automatically answers any line that is ringing at a voice mail port. As a default, the system automatically enables ringing line preference for any port that you have identified as a voice mail port. You must choose a ringing assignment for the lines that you have assigned to the voice mail ports before the voice mail system can provide the automatic attendant feature.
Page 221 IMI66–107 Digital Telephone System Assign The Voice Mail Stations To Hunt Group Description: You must assign all voice mail ports to a circular hunt group to take advantage of that feature’s multiple-port interface capability. Make a circular hunt group by linking all voice mail ports to one another and then linking the last voice mail port in the hunt group with the first voice mail port in the hunt group.
Page 222: Automatic Transfer Of Voice Mail
Digital Telephone System IMI66–107 3.14.2 Automatic Transfer of Voice Mail Description: Use this programming feature to arrange for an immediate connection of a transferred line from voice mail to a digital station port. To Program: 1. Dial 25. “V MAIL AUTO XFER” 2.
Page 223: Voice Mail Transfer On Busy
IMI66–107 Digital Telephone System 3.14.4 Voice Mail Transfer on Busy Description: Normally, the auto-attendant routes calls from a busy station to that station’s voice mail box. Alternately, you can arrange for the system to alert the busy station when the voice mail system is attempting to transfer a call.
Page 224: Positive Disconnect Supervision
Digital Telephone System IMI66–107 3.14.6 Positive Disconnect Supervision Description: When a station is on line with an outside caller and the caller hangs up, the CO may send a positive disconnect signal to the DSU. You can enable the positive disconnect supervision feature on a per-line basis.
Page 225: Versatile Voice Processing
Using The Tracker Paging System With Versatile Voice Processing Description: The Tracker is available for use with the Comdial DSU. To make effective use of a Tracker paging system used in conjuction with the Versatile Voice Processing, program two mail boxes for each person using a Tracker. The second mail box will be used to park the caller and track the called person.
Page 226: Using Tracker For Message Notification
Digital Telephone System IMI66–107 3.15.2 Using Tracker For Message Notification Description: You can program the Tracker to notify mail box users when they have new messages. To Program: In the Message Delivery field for all mail box owners with a Tracker, enter the following: ,*01,X 3.15.3 Transferring Callers To Voice Mail...
Page 227: Visual Voice Mail Support
Visual Voice mail (VVM) support provides proprietarty, two-line display LCD speakerphone stations with visual messages and interactive buttons. This message and button functionality enhances the station’s use with Comdial Versatile Voice Processing (VVP) voice mail equipment. To Program: 1. Press ITCM #746 “CONFIG.
Page 228: Integrated Call Costing
Digital Telephone System IMI66–107 3.16 Integrated Call Costing Call costing provides a means of establishing costing that the system can apply to outside calls made from system telephones. Call costing computes charges for a call after it is completed. It does not restrict dialing as toll restriction does.
Page 229: Call Costing Flow Diagram Examples
IMI66–107 Digital Telephone System 3.16.1 Call Costing Flow Diagram Examples Call Costing Flow Diagram System Programming 3 – 117...
Page 230 Digital Telephone System IMI66–107 Example A For Local Dialing Sequence (201-nnnn) For this example, assume that you have installed the digital telephone system in a location where callers have an opportunity to dial number combinations that contain a common sequence in both the area and office code.
Page 231 IMI66–107 Digital Telephone System Example B For Long Distance With Office Code Dialing Sequence (1-201-201-nnnn) The illustrated sequence is a long distance call (more than 10 digits) with 201 as both the area code and the office code. Program call rate table 25 to cost calls of this sequence. Also, program the zone call band table by adding office code 201 to area code 201 in band one.
Page 232 Digital Telephone System IMI66–107 Example C For Long Distance Dialing Sequence (1-201-nnn-nnnn) This illustrated sequence is a long distance call (more than 10 digits) with 201 as the area code. Program call rate table 11 to cost calls in this sequence. Also, program the area code band table by adding area code 201 to band one.
Page 233 IMI66–107 Digital Telephone System Example D For Exception Dialing Sequence (nnn-nnnn, 1-nnn-nnnn) Program call rate table one to cost calls that do not match any other programmed call rate table. System Programming 3 – 121...
Page 234 Digital Telephone System IMI66–107 Typical SMDR Call Report For The Call Costing Examples 12/28/90 16:05 2014567 $0.50 (see note 1) 12/28/90 16:06 12017894567 $1.35 (see note 3) 12/28/90 16:08 12014785693 $1.12 (see note 3) 12/28/90 16:11 2012014563 $2.50 (see note 2) 12/28/90 16:12 5551212 $1.00 (see note 4)
Page 235: Exception Tables (Local Calls And Long Distance Calls)
IMI66–107 Digital Telephone System 3.16.2 Exception Tables (Local Calls And Long Distance Calls) Description: The system compares all calls to entries in four exception tables (one entry per table). These tables provide the first priority level of costing. The system searches these tables on a first match basis.
Page 236: Office Code Band Tables (Local Calls)
Digital Telephone System IMI66–107 3.16.3 Office Code Band Tables (Local Calls) Description: The system measures the number of dialed digits in calls that do not match exception tables. It compares calls with numbers that have less than 10 digits (local calls) to entries that you have made in office code banding tables.
Page 237: Zone Call Band Tables (Long Distance Calls)
IMI66–107 Digital Telephone System 3.16.4 Zone Call Band Tables (Long Distance Calls) Description: In certain heavily populated geographic areas, different area codes exist within the same geographic distance (zone) from the calling location. In these cases, use zone call band tables to cost calls based upon the zone, or geographic distance, from the calling location.
Page 238: Area Code Band Tables (Long Distance Calls)
Digital Telephone System IMI66–107 3.16.5 Area Code Band Table (Long Distance Calls) Description: The system compares the long distance calls that do not match entries in zone call band tables to entries that you have made in area code band tables. Area code band tables are the third priority level of costing for long distance calls.
Page 239: Call Rate Tables (Local And Long Distance Calls)
IMI66–107 Digital Telephone System 3.16.6 Call Rate Tables (Local And Long Distance Calls) Description: The system compares local calls and long distance calls that do not match entries in any exception table, office code band table, zone call band table or area code band table with the entries that you have made in call rate tables 2–10 and 29–33.
Page 240 Digital Telephone System IMI66–107 To Program: 1. Dial 76. “CALL COST TBL ” 2. Dial table number (01–33). “CALL COST TBL XX” 3. Dial 1 to enter matching digits. “XXXXXXXX ” NOTE: Call Cost Table 1 will not accept matching digits. 4.
Page 241: Discard Digits
IMI66–107 Digital Telephone System 3.16.7 Discard Digits Description: When the digital telephone system is installed behind a host system such as a PBX or CENTREX, users must dial access codes before obtaining an outside line dial tone. To ensure that the system costs a call on just the actual telephone number that the user dials, you should arrange for the system to ignore these access codes.
Page 242: Dialing Time And Answer Time
Digital Telephone System IMI66–107 3.16.8 Dialing Time And Answer Time Dial Time Limit Description: The system does not include dialing time when it records the time of a call for costing. You can program the amount of time that the system ignores for dialing purposes. To Program: 1.
Page 243: Lcd Speakerphone Display Of Costed Calls
IMI66–107 Digital Telephone System 3.16.9 LCD Speakerphone Display of Costed Calls Description: When you arrange the digital telephone system to cost the calls, you should also arrange for the LCD speakerphones being employed with the system to display the cost of each call the user make from that station.
Page 244: Specialized Route Access
Digital Telephone System IMI66–107 3.17 Specialized Route Access (SRA) The SRA feature allows the system to select a line group based on the digits the user has dialed. By doing this, it matches calls with their ideal routes. The feature provides a table-driven routing scheme where the numbers the users dial cause the system to chose a line group after comparing the dialed number with entries in an office code table, and area code table or, four special area code tables.
Page 245: Enable Sra Office And Area Code Tables
IMI66–107 Digital Telephone System 3.17.2 Enable SRA Office Code And Area Code Tables Description: The office code table matches a dialed office code with one of the office codes that you have entered in the table, and routes the call over the line group that you have entered for that office code.
Page 246 Digital Telephone System IMI66–107 Area Code Table To program: 1. Type I 7 4 6 and press RETURN. 2. From the main menu, type 1 and press RETURN for system COS menu. 3. From the system COS menu, type 16 for specialized route access menu and press RETURN.
Page 247: Enable Special Sra Area Code Tables
IMI66–107 Digital Telephone System 3.17.3 Enable Special SRA Area Code Tables Description: The four special area code tables must first match a dialed area code and then match the dialed office code with office code entries in the matched table. With a complete match found, the system routes the call over the line group that you have assigned to the matched office code in the matched special area code table.
Page 248 Digital Telephone System IMI66–107 Assigning line groups to the special office code entries, To Program: 1. From the system COS menu, type 16 for specialized route access menu and press RETURN. 2. From specialized route access menu, type 4 for special area code table menu and press RETURN.
Page 249: Insert Digits For Sra
IMI66–107 Digital Telephone System 3.17.4 Insert Digits For SRA Description: You may program the system, on a per line group basis, to insert up to 8 digits before a dialed number. This feature is useful if the dialed number must match a specific format for the group being used.
Page 250: Sra Overflow Line Group
Digital Telephone System IMI66–107 3.17.5 SRA Overflow Line Group Description: You can assign an overflow line group that the system can route calls over when no lines are free in the line group assigned to the matching entry; otherwise, the system will return busy tone to the caller when this condition exists.
Page 251: Sra Wait Time
IMI66–107 Digital Telephone System 3.17.6 SRA Wait Time Description: Once a caller begins to dial digits, he or she has a certain period of time in which to dial each new digit. After the caller has stopped dialing digits and the end of the time-out period has occurred, the system analyzes the dialed digits and routes the call by following the table-driven routing scheme.
Page 252: Feature Inhibit Programming
Digital Telephone System IMI66–107 3.17.7 Feature Inhibit Programming Description: You can disable certain features system-wide to provide a basic telephone system for use in installations where unauthorized users have access to the stations and may tamper with them. You can re-enable disabled features by dialing 34 while you have the feature inhibit programming feature active or by performing the system default procedure.
Page 253: Station Message Detail Accounting/Reporting (Smda/Smdr)
Digital Telephone System IMI66–107 3.18 Station Message Detail Accounting/Reporting (SMDA/SMDR) The system produces five different call cost reports for printing: 1. Detailed report of all stations. 2. Detailed report of all accounts. 3. Trunk summary report. 4. Department summary report. 5.
Page 254: Smda Department Numbers
IMI66–107 Digital Telephone System 3.18.1 SMDA Department Numbers Description: Use this programming feature to define different SMDA department numbers To Program: 1. Dial 75. “SMDA PROGRAMMING” 2. Dial 04 to define department numbers. “SMDA DEPARTMENTS” 3. Dial 1–8 for department 1–8. “DEPT X”...
Page 255: Smda Printout
Digital Telephone System IMI66–107 3.18.3 SMDA Printout Automatic SMDA Reports Description: Call cost reports, produced by the system for printing, are generated automatically whenever the system detects that the records storage area is ninety-five percent full. Program the system to automatically generate these reports for printing at a certain time each day if desired.
Page 256 IMI66–107 Digital Telephone System SMDA Report Printout Description: You can command the system to print several different types of SMDA reports and to delete all stored SMDA records. NOTE: The departmental call distribution report reflects statistics based on current departmental station assignments. Before you use the previous programming feature to reassign stations to different departments, it is a good practice to: (1) print the departmental call report and any other desired SMDA reports, (2) make any desired reassignments, (3) delete all SMDA records.
Page 257: Smdr Printout
Digital Telephone System IMI66–107 3.18.4 SMDR Printout SMDR Printout As System Collected Description: With this programming step, SMDR provides continuous printout of system-wide station call activity as it is collected by the system. To Program: 1. Dial 77. 2. Dial 2. “SMDR PRINT XXX”...
Page 258: Smda Records Deleted By The Attendant
IMI66–107 Digital Telephone System 3.18.5 SMDA Records Deleted By The Attendant Description: This programming step gives the attendant station the ability to delete SMDA records when commanded to do so by its user. During day-to-day system operation, when SMDA records exceed storage capacity, the attendant can delete current records to make room for additional ones if you perform this programming step.
Page 259: Toll Restriction Tables
IMI66–107 Digital Telephone System 3.19 Toll Restriction Tables The toll restriction feature uses entries that you make in 16 different tables to prohibit some or all stations from calling a wide range of number combinations. In order for toll restriction to take effect, you must complete the following three-fold process: •...
Page 260: Assign Entries To Toll Restriction Tables
Digital Telephone System IMI66–107 3.19.1 Assign Entries To Toll Restriction Tables Description: Plan and execute system toll restriction in the sequence detailed in the following steps. 1. Determine the types of dialing restrictions that you wish imposed on the system. Typically, this includes access codes which result in toll charges, and certain local numbers as desired.
Page 261: Programming Toll Restriction Table Entries
IMI66–107 Digital Telephone System 3.19.2 Programming Toll Restriction Table Entries To Program: 1. Dial 71. “TOLL TABLE” 2. Dial 01–16 —OR— press A1–A14, B1, B2 for toll table 1–16. “XXXXX TABLE Y” 3. Establish an allow or a deny table (A1 LED on = allow, A2 LED On = deny) —Dial 5 or press A1 for allow “ALLOW TABLE Y”...
Page 262: Assign Toll Restriction Tables To Lines
Digital Telephone System IMI66–107 3.19.3 Assign Toll Restriction Tables To Lines Description: Once you have created the toll restriction tables, assign them to lines. To Program: 1. Dial 72. “ASSIGN TOLL-LINE” 2. Dial 01–16 or press A1–A14, B1, B2 for toll table 1–16. 3.
Page 263: Assign Toll Restriction Tables To Stations For Night Transfer (Of Ringing)
IMI66–107 Digital Telephone System 3.19.5 Assign Toll Restriction Tables To Stations For Night Transfer (of ringing) Description: Toll tables assigned with this feature have an effect only when the attendant places the telephone system in the night transfer (of ringing) mode of operation. To Program: 1.
Page 264: Assign Toll Restriction Override (Tro) Code
Digital Telephone System IMI66–107 3.19.7 Assign Toll Restriction Override (TRO) Code Description: The TRO feature allows users to override the toll restriction that they encounter at other stations with their own station’s toll restriction assignments. In programming for this feature, create a four-digit TRO code that users can dial to override the toll restrictions of any station that they happen to be using and replace it with a toll restriction that matches their home station.
Page 265: Positive Disconnect Supervision
IMI66–107 Digital Telephone System 3.19.8 Positive Disconnect Supervision Description: When a station is on line with an outside caller and the caller hangs up, the CO may send a positive disconnect signal to the DSU. You can enable the positive disconnect supervision feature on a per-line basis.
Page 266: The Tracker Paging System
Digital Telephone System IMI66–107 3.20 The Tracker Paging System The optional Tracker Paging System allows users to send alpha/numeric or numeric-only messages to Tracker pagers assigned to station extension numbers. The type of message that the system delivers depends upon the model Tracker Pager being used. You should make a record of all programming decisions that you make—it will help you keep track of what you have done and will help you troubleshoot any problem that might arise later.
Page 267: Preparing The System
IMI66–107 Digital Telephone System 3.20.1 Preparing The System Description: After you install the Tracker base station, you must either master clear the system or default the system data before you take any further programming action to enable the feature. If the Tracker Paging System is part of an initial system installation, you must master clear the system.
Page 268: Enabling The Tracker Pagers For Stations
Digital Telephone System IMI66–107 3.20.3 Enabling Tracker Pagers For Stations Description: After you have enabled the Tracker Paging System as a system-wide feature, enable the Tracker pagers at individual stations. Station users can disable a Tracker Pager by pressing INTERCOM #06 or enable a Pager by pressing INTERCOM 06. To Program: 1.
Page 269: Digital Voice Announcing (Dva)
IMI66–107 Digital Telephone System 3.21 Digital Voice Announcing (DVA) Digital voice announcing uses a hardware peripheral device (product code DVA01) connected to a digital station port to play pre-recorded announcements and messages during an in-progress call. The DVA stores the pre-recorded messages in its memory for recall when needed. While the DVA is not automatic, it enhances the following features by providing automated voice prompts and dialing instructions to callers;...
Page 270: Programming For Dcd Operation
Digital Telephone System IMI66–107 3.21.1 Programming For DCD Operation Description: When you plan to enhance DCD operation with the DVA, you must first completely program the system for DCD operation. To Program: To enable the system for DCD operation, refer to the instructions in section 3.11, Direct Department Calling and complete the following steps: 1.
Page 271: Programming For Disd Operation
IMI66–107 Digital Telephone System 3.21.3 Programming For DISD Operation Description: When you plan to enhance DISD operation with the DVA, you must first completely program the system for DISD operation. NOTE: You should set a DISD dial time that is as long as the maximum time needed to complete the longest DVA message.
Page 272: Enabling/Disabling Digital Voice Announcing (Dva)
Digital Telephone System IMI66–107 3.21.4 Enabling/Disabling Digital Voice Announcing (DVA) Description: You can enable DVA support for both DISD and DCD operation. To Program: To assign DVA support for DISD operation. 1. Dial 17. “SYSTEM FEATURES” 2. Dial 07. “DISD DVA XXXXXXX” 3.
Page 273: Programming The Dva Messages
IMI66–107 Digital Telephone System 3.21.5 Programming The DVA Messages Description: You or the system attendant can store the customized messages in the DVA device in one of two ways: by delivering them from the telephone handset at station 10 or 12 or by playing the contents of a professionally-supplied tape recording into the DVA memory.
Page 274 Digital Telephone System IMI66–107 To Program: 1. Dial 08. “DVA TABLE NUM” 2. Choose the message style. —Dial 1 for DISD message style. “PORT NUMBER” —Dial 2 for DCD message style. “PORT NUMBER” 3. Select DVA station ports —Dial 10–57 or press C10–C57 (LED On = Selected). 4.
Page 275: The Data Interface Unit
IMI66–107 Digital Telephone System 3.22 The Data Interface Unit The Data Interface Unit (DIU) is a device connected to a digital station port of a DSU. The DIU provides connection for a digital multiline telephone and another device such as an Industry standard telephone (IST), FAX, or modem.
Page 276: Remote Data Station
Digital Telephone System IMI66–107 3.22.2 Remote Data Station Description: Use this procedure to program the system to allow remote control of a DIU from one or more multiline digital telephones assigned to other station ports. Remote commands are blocked when the station is busy with a call. To Program: 1.
Page 277: Caller Id Service Support
IMI66–107 Digital Telephone System 3.23 Caller ID Service Support When you subscribe to Caller ID service, the central office sends Caller ID data over the lines. After the Caller ID device deciphers the data, it is displayed on a system LCD speakerphone. You must program lines and stations for Caller ID service.
Page 278 Digital Telephone System IMI66–107 Table 3–11: Caller ID Information On SMDR Printout Called Call Answer Call # Station # Line # Date Time Call Cost length Time Calling # 123456789 1000 10/15/92 04:38 $ 0.51 0123456 10/15/92 00:56 5551212 10/15/92 00:56 NOANS /5551234...
Page 279 IMI66–107 Digital Telephone System As an option, you can arrange for the system to provide Caller ID data distribution through the RS232 data port B to a personal computer (PC) just as it supplies SMDA data to a data printer. This data consists of four special-purpose messages and is in the ASCII format suitable for use with PC-based application programs.
Page 280: Assigning Caller Id Lines (Required Programming)
Digital Telephone System IMI66–107 3.23.1 Assigning Caller ID Lines (required programming) Description: Programs lines to receive Caller ID service. To Program: 1. Dial 47. “CALLER ID LINES” 2. Select line ports (LED On = Selected) Line Port 1–14 = Dial 01–14 or A1–A14 Line Port 15, 16 = Dial 15, 16 or press B1, B2 Line Port 17–24 = Dial 17–24 or press HOLD and then press A1–A8.
Page 281: Configuring Rs232 Data Port B (Required Programming)
IMI66–107 Digital Telephone System 3.23.3 Configuring RS232 Data Port B (required programming) Description: Configures RS232 Data Port B to receive Caller ID data. To Program: 1. Dial 15. “BAUD RATE” 2. Dial 2 for data port B. 3. Press A10 for 9600 baud. “W nD nS 9600"...
Page 282: Setting The Caller Id Distribution (Optional Programming)
Digital Telephone System IMI66–107 3.23.5 Setting The Caller ID Distribution (optional programming) Description: Sends Caller ID information to data port B for access by a PC. To Program: 1. Dial 17. “SYSTEM FEATURES” 2. Dial 02. “CID DISTRIBUTION” 3. Dial 1 to enable Caller ID distribution (LED on) —OR—...
Page 341: A Appendix A
IMI66–107 Digital Telephone System Appendix A: Understanding The System Features Abandoned Hold Release If an on-hold party hangs up at the CO/PBX end of a connection, causing an interruption in the line current, the system will drop the line from the hold condition and return it to service.
Page 342 Digital Telephone System IMI66–107 Account Codes (With Forced Positive Verification) System users can employ account codes to identify calls by category or by any other desired grouping so that the system can print reports. The account code entry can be voluntary or the programmer can arrange the system so that the users are forced to enter an account code before they can make an outgoing call.
Page 343 IMI66–107 Digital Telephone System but cannot be lower than the verified account code length. The verified account code length defines the number of digits that the system will verify before it accepts an account code as valid. As well, verified account code length defines the number of valid account codes that a programmer can store (as shown in the following table).
Page 344 Digital Telephone System IMI66–107 Forced Account Code Entry For CENTREX Users The programmer may set the TAP time so that CENTREX users do not have to re-enter an account code after pressing the TAP button. The programmer may also set the system so that non-CENTREX users do have to enter an account code after pressing TAP.
Page 345: Area Paging Interface
IMI66–107 Digital Telephone System connections. It contains a ringing generator to generate a ringing signal for the IST devices. Area Paging Interface Any station user can dial a special code number in response to an all-call or zone page and be connected to the paging party in a private conversation. All-call or zone paging is provided to the stations through the station class of service programming.
Page 346: Automatic Dialing
Digital Telephone System IMI66–107 Automatic Dialing Of Stored Numbers Automatic Dialing The system supports up to 24 automatic dial (autodial) numbers per station. Autodial buttons can store up to 16 digits plus an intercom or line selection. Stored digits include 0–9, and #.
Page 347: Automatic Hold For Intercom
IMI66–107 Digital Telephone System Automatic Hold For Intercom If a user selects the second intercom line while a call is active on the first intercom line, this automatic hold feature lets the system automatically place the first intercom call on hold.
Page 348: Auxiliary Equipment Interface
Digital Telephone System IMI66–107 Automatic Station Relocation With this feature, the system will automatically recognize a particular station should that station be relocated to a new station port. When someone places a telephone at a new port location, it will continue to provide the same class of service parameters and respond to the same extension numbers as it did at the original station port.
Page 349: Background Music
IMI66–107 Digital Telephone System Background Music If the installer connects a customer-provided external music source to the system, the music from that source will sound through the station loudspeakers after the users turn it on at their stations. They can adjust the loudness of this background music with the loudspeaker volume control.
Page 350 Digital Telephone System IMI66–107 Block Programming A programmer can assign a particular line or station’s class of service to an entire block of lines or stations with one programming action. This feature eliminates the need for him or her to individually program stations and lines with the same class of service. A programmer can perform a block programming class of service after he or she has programmed a station class of service or line class of service for a particular station or line.
Page 351 IMI66–107 Digital Telephone System The system will automatically provide a report whenever the costed call storage reaches 95 percent of capacity. Additionally, the programmer can arrange for these reports to be printed automatically at a specific time of day. The system can produce five different SMDA records: •...
Page 352: Call Forwarding
Digital Telephone System IMI66–107 Station Message Detail Recording (SMDR) The SMDR feature generates a call record for printing as soon as the system collects the record. It presents the call record at an RS-232 level as ASCII transmit data in an 80-column format at the data port available for that purpose.
Page 353 IMI66–107 Digital Telephone System Ring-No-Answer Forwarding Of Transferred Calls This feature enhances the existing automatic RNA call forwarding feature to include forwarding of transferred lines to individual stations. When a telephone user transfers a line to a station, the call will ring at the station receiving the transfer for the programmed number of rings.
Page 354: Call Park
Digital Telephone System IMI66–107 Call Park The call park feature is similar to a manual hold condition. A user can park a call a particular station and retrieve it at any station in the system by dialing the appropriate access code. NOTE: The retrieving station must have access to the line on which the call appears.
Page 355: Call Waiting Tone
IMI66–107 Digital Telephone System Unanswered Call Transfer Recall Timing A transferred call that is unanswered after a pre-programmed length of time will return to the station that transferred it. The system will return the call to both attendant stations when the tandem attendant feature is enabled. When LCD speakerphones are employed, the display will show the station number or name as well as the line number that is being re-called.
Page 356: Class Of Service
Digital Telephone System IMI66–107 (seven-, eight-, and eleven-digit Caller ID numbers are already in a format that can be dialed and do not need to be transformed.) The system will dial those numbers that are present in the 6-digit table as local calls even if they are in different area codes.
Page 357: Class Of Service Program Printout
IMI66–107 Digital Telephone System features that require periodic change by entering COS programming with another code provided for this purpose. The station user can program individual stations for speed dial, autodial and direct station selection (DSS) by entering COS with a code provided for that purpose.
Page 358: Remote Programming And Administration
Digital Telephone System IMI66–107 desired. After a programmer has reprogrammed a system, he or she can re-default it by using the system, line, and station class of service programming or use a master clear to default the entire system and erase all stored programmable button information. Remote Programming And Administration Both remote class of service programming and the transmission of SMDR data for printing are available through serial data ports.
Page 359: Console Support
IMI66–107 Digital Telephone System Console Support The digital telephone system supports the installation and use of a DSS/BLF console at any available station port. The number of installed consoles is limited only by port availability; however, since a console complements a companion telephone located in an adjacent station port, the installer can use up to one-half of the available station ports for consoles.
Page 360: Data Interface Unit
Digital Telephone System IMI66–107 While the first console (the one installed at the logic-paired port) extends the autodial buttons of the paired telephone by 48 and provides DSS/BLF coverage for station ports 10 through 57, the second console (the one installed at the programmed station port) provides DSS/BLF coverage as follows: •...
Page 361 IMI66–107 Digital Telephone System The user controls the DIU by pressing a preprogrammed DATA button on his/her digital telephone. The installer can also program a DATA button on a remote telephone that can control the DIU as well. The DATA LED on the digital telephone provides the user with visual feedback on DIU status.
Page 362: Delayed Ringing
Digital Telephone System IMI66–107 Delayed Ringing Ringing assignments are programmable. A station can be programmed to provide delayed ringing on some lines while providing immediate ringing on other lines. Delayed ringing is assigned to certain lines at each station through station class of service programming.
Page 363 IMI66–107 Digital Telephone System The Dial By Name feature uses the seven-character station names associated with the station ports for searching through the list of stations for intercom calling. 16-character names are used for searching through the list of system speed dial entries. When users make a sequential search through the stored index of names, the system searches the list as it was entered.
Page 364 Digital Telephone System IMI66–107 Night Answer Messages For DCD callers—“Welcome to Acme’s sales department. Our hours are eight to four-thirty. Please call tomorrow during those hours.” For DISD callers—“Welcome to Acme Company. Our hours are eight to four-thirty. Please call tomorrow during those hours.” Recall Messages For DCD callers—“Please hold.
Page 365 IMI66–107 Digital Telephone System 4. A DISD line recalls to the DSU after a transfer recall time, and the DVA plays a recall message to the caller. The DSU transfers the call once more to the same or different stations. This action repeats three times. 5.
Page 366 Digital Telephone System IMI66–107 dropped by the caller. The caller continues to receive ringback tone until the call is answered. The overflow station can service the call or transfer it back to the department using the department pilot number. When the call is transferred back to the department by an overflow station, it will not return to the overflow station until that station is idle and has no ringing calls either new or transferred.
Page 367 IMI66–107 Digital Telephone System A department station can also be taken out of service and placed in a wrap-up mode to provide the user time for doing such things as follow-up paperwork. While a station is in a wrap-up mode, all outside and transferred calls skip to the next department station. The station user sets the wrap-up mode by pressing Hold DND and presses these buttons again to clear the wrap-up mode.
Page 368 Digital Telephone System IMI66–107 Wrap-Up Time: The time that a station spent in a wrap-up mode doing such things as follow-up paperwork. While a station is in a wrap-up mode, it does not receive department calls. The station user sets a wrap-up mode by pressing Hold and DND and repeats the procedure to clear the wrap-up mode.
Page 369 IMI66–107 Digital Telephone System The number of rings which occurs on a DISD line before it is answered is programmable. By setting a large number of rings, time is allowed for a call to be serviced in a regular manner by stations that have a line appearance for the DISD line. Setting the number of rings to 0 disables the line for DISD use.
Page 370: Distinctive Ringing
Digital Telephone System IMI66–107 Direct Station Call Hold (Station Park) This feature allows a station user to park a call at a specific station where it will be held without ringing. A feature code plus a station extension number can be dialed over the intercom line to park the call or a programmable button can be programmed to provide a “directed hold”...
Page 371: Do Not Disturb Override
IMI66–107 Digital Telephone System Do Not Disturb Inhibit The system can be programmed to inhibit any station from entering the DND mode. System class of service programming is used to program this feature. Do Not Disturb Override Stations can be provided with DND override capability which will allow them to call a station that is set in the DND mode.
Page 372 Digital Telephone System IMI66–107 Dynamic Line Buttons Through class of service programming, the programmer can arrange certain idle line buttons to serve as dynamic line buttons. This feature allows the system to temporarily assign a line to a station that normally does not have the line assigned to it, and have that line appear on a dynamic line button.
Page 373: Feature Inhibit
IMI66–107 Digital Telephone System Executive/Attendant Override This feature allows the user of a station, upon encountering a busy signal at another station, to dial a code that will override the busy signal of a call, sound a warning tone, and allow access to the existing conversation. This feature is enabled through station class of service programming.
Page 374 Digital Telephone System IMI66–107 Flexible Ringing Assignments Of PA Port The PA port can be programmed for flexible ringing assignments and zone pages. Any desired lines can be programmed for direct ring, delay ring, or night transfer (of ringing) at this port. Paging can be to programmed zone or to all-call. A speaker can be connected to the PA port to sound the ringing that is generated by the system and sent to this port and paging announcements when they are sent to the programmed zone.
Page 375: Headset Capability
IMI66–107 Digital Telephone System Full Button Programmability Of Features A programmer, or in many cases the users themselves, can make most system features available at programmable buttons merely by storing the specific access codes necessary for dialing the features. Storable features include those that can utilize lamp (on/off) supervision (e.g., call park orbits).
Page 376 Digital Telephone System IMI66–107 Hold Abandoned Hold Release If an on-hold party hangs up at the CO/PBX end of a connection, causing an interruption in the line current, the system will drop the line from the hold condition and return it to service.
Page 377: Manual Hold
IMI66–107 Digital Telephone System Exclusive Hold Exclusive hold prohibits a held call from being retrieved by any other station. The exclusive hold condition also links the held call to the timed hold recall timeout feature. After timeout, the system causes audible and visual signaling to occur reverts the exclusive hold condition to a normal line hold condition.
Page 378 See also, Line Features. Impression Telephone Support The digital telephone system supports the use of Comdial Impression digital telephones. This new proprietary digital telephone style is available in the following models: 2022S–FB and –PT LCD Speakerphone 2122S–FB and –PT...
Page 379: Intercom Features
IMI66–107 Digital Telephone System the handset is lifted) or places the outside line on hold (if digits are dialed) and causes intercom dial tone to return to the IST. Pressing and releasing the hookswitch is commonly known as flashing the hookswitch or performing a FLASH.
Page 380 Digital Telephone System IMI66–107 • Intercom call to station already busy on intercom rings in subdued fashion and flashes indicator associated with other intercom button. • With both intercom lines busy, a third intercom call results in a subdued off-hook voice announce (if enabled) at busy station.
Page 381: Last Number Redial
IMI66–107 Digital Telephone System Tone Or Voice Signaling The system allows intercom calls to be tone signaled or voice signaled as the users desire; however, the programmer uses system class of service programming procedures to determine which signaling method the system will employed as the primary method. Regardless of the programmer’s arrangement, telephone users can take action to use the alternate method when they need it.
Page 382: Interactive Button Support
Digital Telephone System IMI66–107 preference. If they are unavailable, the system will chose the last line used at the station. If it is busy, no further choice is made. No class of service is required. See also, Redialing. LCD Messaging Standard and system-supplied custom display messages can be set by dialing a specific code at any station.
Page 383: Line Groups
IMI66–107 Digital Telephone System Line Features Access Denied, Line Access Restriction The system programmer can deny access to particular lines at certain stations in the system. A station user cannot select a denied line for use. This feature is programmable on a per line/per station basis in station class of service programming.
Page 384: Line And Line Group Queuing
Digital Telephone System IMI66–107 Line And Line Group Queuing With the line queuing feature, the station user can take action that will place a station in a queue where it awaits the availability of a line or line group. The station is automatically signaled with five-ring bursts when the line is available to it for use.
Page 385 IMI66–107 Digital Telephone System Manual Hold A button activated feature at each station will place an outside line on hold. When a user presses the HOLD button while on a call, the system places the call on hold, provides a distinctive flash rate of the line button indicator, and allows the user to access other station features.
Page 386: Message Waiting
Digital Telephone System IMI66–107 LCD Messaging Standard and system-supplied custom display messages can be set by dialing a specific code at any station. Such messages are to be received and displayed by any LCD speakerphone that calls the station which set the message. When a message is set, the intercom light at the setting station will flash to indicate that the feature is active.
Page 387 IMI66–107 Digital Telephone System Modular Wiring And Jacks 2- Or 4-Conductor Wire System The system can be completely interconnected by employing industry standard 50-pin connectors and modular plug/jack combinations. Station wiring is number 22 or 24 gauge, 2-conductor, twisted-pair cable throughout the system. If the installer uses 4-conductor twisted-pair cable, it provides a spare pair for a separate wiring purpose when needed.
Page 388: On-Hook Dialing
Digital Telephone System IMI66–107 Handsfree Answer Inhibit The user can use the MUTE button to block all handsfree answerback response. This arrangement will prevent a station user from monitoring another station site using the monitoring ability of the voice announce feature. When a user presses the MUTE button, all handsfree answerback is disabled thus inhibiting any off-site monitoring.
Page 389: Zone Paging
IMI66–107 Digital Telephone System Paging All-Call Paging All-call paging allows all stations to receive announcements through the station speaker at once. The system can also send all-call paging to the paging port where it applies it to the input of an external paging amplifier. Origination of announcements must be via the station handset.
Page 390 Digital Telephone System IMI66–107 PBX/CENTREX/CO Compatible System features and programmable buttons support the requirements of most PBXs, Central Offices, and CENTREX systems. Numbers, #‘s, ‘s, programmable pauses, and flash signals can be made a part of every stored number for access to host system feature codes.
Page 391: Power Failure Transfer
IMI66–107 Digital Telephone System Power Failure Transfer An installer can connect an industry-standard telephone such as the model 2500 to a special connection to serve as a power-fail telephone. If an AC power failure occurs, the system automatically connects the power-fail telephone directly to an outside line. Users can make normal origination and reception of calls on a power-fail telephone during an AC power failure.
Page 392: Programmable Buttons
Digital Telephone System IMI66–107 Privacy Release/Brokerage Service See the previous paragraph titled Privacy—Designated Programmable Button Private Lines (Access Denied) The system programmer can deny access to particular lines at certain stations in the system. A station user cannot select a denied line for use. This feature is programmable on a per line/per station basis in station class of service programming.
Page 393 IMI66–107 Digital Telephone System Programming Password Protection No one can enter a programming mode to reprogram the system without first entering a password. The system provides two different entry levels for programming and allows for a different password for each entry. The two programming entry levels are the installer level and the administrator level.
Page 394 Digital Telephone System IMI66–107 Redialing Automatic Redial (Of Busy Number Or Unanswered Call) A user can automatically redial a busy number or unanswered call by activating this feature. Once the user activates automatic redial, the station will select the line, automatically dial the number, and wait for a response.
Page 395: Response Messaging
IMI66–107 Digital Telephone System Response Messaging This feature allows a user to reply in a non-verbal manner to a voice announce or tone-signaled intercom call or to a subdued off-hook voice announce call if the intercom caller is using an LCD speakerphone. A station user can press a programmable button in response to an intercom call and send a message to be shown on the display of the calling station.
Page 396 Digital Telephone System IMI66–107 of an external paging amplifier and the installer can arrange the wiring so that the relay closures energize the paging amplifier while it is receiving the ringing tone. Use system class of service programming to choose either the paging port. or station port 17 for the ringing port relay control.
Page 397: Subdued Ringing
IMI66–107 Digital Telephone System and paging announcements when they are sent to the programmed zone. Using such an arrangement, it is possible for a user to determine that certain lines are ringing, such as in a night transfer (of ringing) mode, and go to the nearest telephone and answer the call. The most common use for this arrangement is as a night bell eliminating the need for external equipment as required with the common ringer and auxiliary ringer interface.
Page 398: Saved Number Redial
The Scout does have a range test that the installer or user can perform. Comdial highly recommends that the installer perform a preliminary on-site range test to make sure the Scout meets the customer’s needs (for more information on how to use the range-test...
Page 399: Specialized Route Access
LCD will indicate “System Busy” and deny the call. If you do install more than one Scout wireless telephone, Comdial recommends that you leave at least 10 feet between adjacent base units. The range of each Scout telephone is affected by the layout and location of the base unit, so it is a good idea to install the base unit in an unimpeded area and at desk-level or higher.
Page 400 Digital Telephone System IMI66–107 a line group after comparing the dialed number with entries that are contained in an office code table, an area code table, and four special area code look-up tables. The specialized route access operates in the following manner: When the caller presses INTERCOM and dials 9 or presses a preprogrammed button, the system returns a special dial tone.
Page 401 IMI66–107 Digital Telephone System The following information illustrates the digit evaluation scheme. Digit Evaluation Digits Evaluated By Quantity Of Digits Actual Dialed Digits System To Find Line Dialed Group 5123 9782200 19782200 8049782200 804, 978 18049782200 804, 978 The example below shows how calls to area code 202 are routed using line group 2, calls to office code 202 are routed using line group 1, calls to office code 973 in area code 716 are routed using line group 4, and all other calls are routed using line group 1.
Page 402 Digital Telephone System IMI66–107 that the CENTREX extensions are 3300–3399. Take programming action to assign line group 2 to entries 330–339 in the office code table. This means that calls on CENTREX extensions will use line group 2 and all other calls will default to use line group 1. Program the 9 digit as the insertion digit for line group 1.
Page 403: Tenant Service
IMI66–107 Digital Telephone System Flexible Station Numbering Plan The system supports a flexible station numbering plan for individual stations. Each station can be programmed to respond to the dialing of any available number between 10 and 7999. This feature may be used to match the calling number of a station located in a pre-numbered area to that area number.
Page 404 Digital Telephone System IMI66–107 Station-To-Station Messaging If a station has a DSS/BLF appearance at another station, a callback message indication can be left at that station with the DSS/BLF appearance. The user can dial a special code to turn on the BLF light at the called station that is assigned to the calling station. This light indicates that a callback is requested.
Page 405 IMI66–107 Digital Telephone System Subdued Off-Hook Voice Announce (SOHVA) Groups The programmer can program the ability of station ports to originate and/or receive SOHVA calls by assigning SOHVA calling groups to station ports. This means that he or she can arrange certain station ports together for SOHVA calling between one another while excluding other station ports in the system from this group.
Page 406: System Alarm Reports
Digital Telephone System IMI66–107 Example 1: Allow station port 10 to originate SOHVA messages to all stations in the system and allow those stations the ability to originate SOHVA messages to each other but not to station port 10. Assign group 1 to station port 10 and assign group 2 to all other station ports.
Page 407 IMI66–107 Digital Telephone System Tandem Attendant When the programmer uses system class of service programming to enable the tandem attendant feature, a recall from an unanswered call transfer or a timed hold recall will ring at the normal attendant station (station 10) that set the transfer or hold condition, and also ring at the tandem attendant station (station 12).
Page 408: Toll Restriction
Digital Telephone System IMI66–107 Toll Restriction Default Toll Restriction The system defaults two toll restriction tables with pre-programmed values and pre-assigned to all lines. The programmer needs only to assign these tables to the stations by programming action to put them into effect. He or she can use the toll restriction table configuration class of service programming to reprogram the defaulted tables with different information as needed.
Page 409: Toll Restriction Override
IMI66–107 Digital Telephone System tables replace any that he or she may have assigned to the station for normal, or day mode, operation. For example: a programmer can arrange for a station that has no other toll restriction table assignment to receive a toll restriction table which will restrict everything but local calls and will only take effect when the system is placed in the night transfer (of ringing) mode.
Page 410: Transferring Calls
Digital Telephone System IMI66–107 Tracker Paging System The optional Tracker Paging System is a wireless paging system that uses an external base station connected to the common equipment cabinet and individual portable pagers assigned to the system station extension numbering plan. The Tracker Paging System allows telephone users to send alpha/numeric or numeric-only messages to Tracker pagers assigned to station extension numbers.
Page 411 This message and button fuctionality enhances the stations with visual messages and interactive buttons. This message and button functionality enhances the station’s use with Comdial Versatile Voice Processing (VVP) voice mail equipment. To implement VVM support, the system programmer must enable it with class of service programming action.
Page 412: Hunt Groups
Digital Telephone System IMI66–107 Voice Announce Blocking This feature allows station users to block voice announced intercom signaling by dialing a code or pressing a programmable button programmed for that purpose. The programmable button used to block voice signaling is enabled by station class of service programming.
Page 413: Volume Control
IMI66–107 Digital Telephone System Positive Disconnect Supervision When a station is on line with an outside caller and the caller hangs up, the CO may send a positive disconnect signal to the digital telephone system. The system passes this signal to the voice mail equipment thus signaling it also to hang up.
Page 414 Digital Telephone System IMI66–107 ringer-off feature on a system-wide basis. When programmers take this option, users can set the ringer volume to a low level but cannot completely silence it. The number of handset loudness levels is different for the different telephone models. The DigiTech telephones have 8 handset volume settings.
Page 415 IMI66–107 Digital Telephone System INDEX Alarm Report Station ..3-77 Alarm Reporting, System ..3-26 Abandoned Hold Release ..3-38, A-1 System Alarm Report, Enabling .
Page 416 Digital Telephone System IMI66–107 Button Designations, Converting ..3-9 Audible Ringing Interface ..2-30 Authorizing Repairs ..2-80 Button Mapping The Stations ..3-79 Automatic Call-Back Button .
Page 417 Identification On BLF ..A-16 To The G0408 ....2-19 Central Message Desk ..3-56 Connecting Stations To The G0816 .
Page 418 Digital Telephone System IMI66–107 Determining The Ringer Equivalence Number ..2-81 Dial 0 For System Attendant ..A-22 Data Baud Rate ... . 3-18 Dial Time Limit .
Page 419 IMI66–107 Digital Telephone System Direct Ringing ....3-59 Direct Station Call Hold (Station Park) ..A-30 Enable Call Waiting Tone ..3-104 Direct Station End-To-End Signaling .
Page 420 Manual Hold ....A-37 Timed Hold Recall ..3-33, A-37 G0408, Connecting Stations To ..2-19 G0816, Connecting Stations To ..2-20 G1632, Connecting Stations To .
Page 421 IMI66–107 Digital Telephone System SMDA Call Report For The Industry-Standard Telephone Support . . A-38 Call Costing Examples ..3-122 Industry/Regulatory Standards ..1-22 SMDR Call Report For The Call Costing Examples .
Page 422 Digital Telephone System IMI66–107 Lines, Defaulting ... 3-13 Line Configurations, Recording . . 4-11–12 Line Connection ... . 2-12 Local Call Exception Table ..3-123 Line Connection Details .
Page 423 IMI66–107 Digital Telephone System Messaging, LCD ... . 3-21 Modular Jack Data Connections ..2-34 Modular Wiring And Jacks Office Code Band 2- Or 4-Conductor Wire System ..A-47 Tables (Local Calls) .
Page 424 Digital Telephone System IMI66–107 Power Failure Transfer ..A-51 Power Requirements ..1-20 Prime Group ....3-68 PA Port .
Page 425 IMI66–107 Digital Telephone System Replacing The Software Cartridge ..2-48–49 Resistance, Checking ..2-51 Radio Frequency Interference ..2-81 Response Messaging .
Page 426 Digital Telephone System IMI66–107 SRA Wait Time ....3-139 Seeking Repair Assistance ..1-25 Using Specialized Route Access Selected Ports, Connecting ..2-30 For Simplified Toll Restriction .
Page 427 IMI66–107 Digital Telephone System System Features ... . . 3-17 Station Numbering, Flexible ..3-62 Station Ports For System Features, Inhibiting ..3-31 Direct Department Calling .
Page 428 Digital Telephone System IMI66–107 Tracker Paging System Toll Restriction Tables ..3-147–153 (Using With Versatile Voice Processing) . 3-113 Assign Entries To Transfer/Conference Button ..A-70 Toll Restriction Tables ..3-148 Transferring Callers To Voice Mail .
Page 429 IMI66–107 Digital Telephone System Voice Or Tone Signaling ..3-30 Voltage, Checking ... . 2-51 Volume Control ... . . A-73 VDT Programming .
Page 430: Limited Warranty
No Comdial dealer nor any other person or entity other than Comdial may extend or modify this warranty, and no such modification or extension shall be effective unless it is in writing.
Page 432 GCA70–250 Quick Reference Appendix A Quick Reference Guide This chart provides you with a Quick Reference Guide of the feature dialing codes. If you wish, you can detach these pages and keep them near your telephone to serve as a stand alone reference. Chapter 8, Programming Your Telephone, describes a method to program these codes on your telephone at unused programmable buttons.
Page 433 Quick Reference GCA70–250 Button Feature Enable Code Disable Code Mnemonic Call Forward, INTERCOM INTERCOM # 5 FWDRA Ring-No Answer, + extension number All Calls Call Forward, INTERCOM INTERCOM # 5 FWDRP Ring-No Answer, + extension number Personal Calls Call Park, Orbit INTERCOM PARK 1–9 91-99...
Page 434 GCA70–250 Quick Reference Button Feature Enable Code Disable Code Mnemonic Line Group 1 INTERCOM 9 LNG01 Line Groups INTERCOM 80-89 LNG02-11 2-11 Line Groups INTERCOM 60-64 LNG 12-16 12-16 Line Pick Up INTERCOM 65-68 TAFS 1-4 From Any Station, Zones Line Pick Up INTERCOM 69 TAFS...
Page 435 Quick Reference GCA70–250 Button Feature Enable Code Disable Code Mnemonic Personal INTERCOM Ringing Tones 4 + tone code (1-8) Redial Last Dialed Number Remote Station INTERCOM INTERCOM Disable 05 + extension 05 + extension number number Response INTERCOM RSPnn (nn = Message 6 + button + 1-30, S)
