INSTALLATION AND CONNECTIONS

Linear Amplifier Connections

Connecting the IC-PW1/EURO
D
To connect the Icom IC-PW1/EURO, see the diagram below.
For IC-PW1/EURO operation, refer to the amplifier's instruction manual.
To an antenna
[ANT]
AC outlet
Non-European versions: 100–120 / 200–240 V
European version: 230 V

D Connecting a non-Icom linear amplifier

To connect a non-Icom HF, 50/70*
* 1 70 MHz band transmission is available, depending on the transceiver version.
To an antenna
Non-Icom Linear amplifier
RF OUT
ACC cable
[ACC-1]
[REMOTE]
EXCITER
1 1&2
IC-PW1/EURO
1
MHz bands linear amplifier, see the diagram below.
RF IN
ALC
SEND
Relay
Switching diode
Remote Control
cable
[INPUT1]
Coaxial cable
[ANT1]
GND
GND
ALC (Blue)
HSEND
(Orange)
IC-7100
/VSEND
13.8 V (Gray)
2
* When connecting a 144 MHz or 430 MHz band's liner am-
plifier, connect to [ANT2].
2-8
7-pin side
OPC-599
conversion
[REMOTE]
cable
[ACC]
GND
IC-7100
2
[ANT1]*
GND
ACC
13-pin plug with ACC cable
