Disable or enable the XPort Direct+'s ability to show the IP address after RING in
Modem Mode. The default is Y (Yes), to show the IP address.
Auto Increment Source Port
Y (Yes) auto increment the source port. The XPort Direct+ increments the port
number used with each new connection.
Remote IP Address
This is the destination IP address used with an outgoing connection.
Note:
This option does not display when Hostlist is enabled from the
ConnectMode prompt (see
Remote Port
You must set the remote TCP port number for the unit to make outgoing connections.
This parameter defines the port number on the target host to which a connection is
attempted.
To connect an ASCII terminal to a host using the unit for login purposes, use the
remote port number 23 (Internet standard port number for Telnet services).
Note:
This option does not display when Hostlist is enabled from the
ConnectMode prompt (see
DisConnMode
This setting determines the conditions under which the unit will cause a network
connection to terminate.
Notes:
In DisConnMode (Disconnect Mode), Modem Control In drop either drops the
connection or is ignored.
All bit positions in the table that are blank represent "don't care" bits, for that
particular option, which can be set to either a 0 or 1 value.
XPort Direct+ User Guide
Auto increment source port (N) ? _
Remote IP Address : ( 0) ( 0) ( 0) ( 0)_
Connect Mode
Remote Port ( 0) ? _
Connect Mode
DisConnMode ( 0) ? _
7: Setup Mode: Channel Configuration
on page 43 for more information).
on page 43 for more information).
50
