Email Settings

The unit sends an email to multiple recipients when a specific trigger event occurs.
There are three separate triggers, based on any combination of the configurable pins
selected as user I/O functions. Optionally, use a two-byte serial string to initiate a
trigger. Each trigger is independent of the others. Each condition within an individual
trigger must be met before the unit will send the email.
To configure the email settings of the XPort Direct+:
1. On the main menu, select Email. The Email Settings window opens.
2. Configure the following fields:
Server IP Address
Server Port
Domain Name
Unit Name
Recipients
Recipient 1: Email
Address
Recipient 2: Email
Address
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.

Trigger Configuration

A trigger event occurs when the unit receives the specified trigger input resulting from
a specified combination of conditions on the configurable pins.
XPort Direct+ User Guide
Figure 4-9. Email Settings
Enter the IP address of the mail server.
Enter the port number on the email server.
Enter the email server's domain name.
Enter the user name used by the XPort Direct+ to send email
messages.
Enter the email address designated to receive email
notifications.
Enter an additional email address designated to receive email
notifications.
4: Configuration Using Web Manager
30
