Set the configurable pins to Active, Inactive, or None. The configurable pins are
disabled if they are all set to None. If both the serial sequence and the configurable
pins are disabled, the trigger is disabled.
To configure the email trigger settings of the XPort Direct+:
1. On the main menu, click Trigger 1, Trigger 2, or Trigger 3 to configure the
desired trigger settings. The Email Trigger Settings page opens.
2. Configure or modify the following fields:
Conditions
Configurable Pins
Enable Serial Trigger
Input
Channel
Data Size
Match Data
Note: All of the conditions must match for the XPort Direct+ to send an email
notification.
Message Properties
Message
Priority
Notification Interval
XPort Direct+ User Guide
Figure 4-10. Email Trigger Settings
Select the condition from the drop-down menu for the
configurable pins. Repeat for each Trigger Input field.
Enabling this option causes specified serial communications
to count as a trigger input.
Select the channel prompting the trigger. For the XPort
Direct+, there is only one channel.
Select the data size prompting the trigger.
Enter the data, which, when it appears in the communication
stream, prompts a trigger.
The subject line of the trigger event email to the specified
recipient(s).
The priority level for the email.
The minimum time allowed between individual triggers. If a
trigger event occurs within the minimum interval since the last
trigger, it is ignored.
