Group
Comments
Device Family
Type
ID
Hardware Address
Firmware Version
Extended Firmware
Version
Online Status
Telnet Enabled
Telnet Port
Web Enabled
Web Port
Maximum Baud Rate
Supported
Firmware Upgradeable
IP Address
Number of COB
partitions supported
Supports Dynamic IP
Subnet Mask
XPort Direct+ User Guide
Configurable field. A group name to categorize the XPort
Direct+. Double-click the field, type in the value, and press
Enter to complete. This group name is not visible on other
PCs or laptops using DeviceInstaller.
Configurable field. Information about the XPort Direct+.
Double-click the field, type in the value, and press Enter to
complete. This description or comment is not visible on other
PCs or laptops using DeviceInstaller.
Non-configurable field. Displays the device family type as
XPort.
Non-configurable field. Displays the device type as XPort
Direct+.
Non-configurable field. Displays the ID embedded within the
XPort Direct+ box.
Non-configurable field. Displays the hardware (or MAC)
address of the XPort Direct+.
Non-configurable field. Displays the firmware currently
installed on the XPort Direct+.
Non-configurable field. Displays the
nomenclature of the firmware.
Non-configurable field. Displays the status of the XPort
Direct+ as online, offline, unreachable (the XPort Direct+ is on
a different subnet), or busy (the XPort Direct+ is currently
performing a task).
Non-configurable field. Permits Telnet sessions.
Non-configurable field. Displays the XPort Direct+ unit's port
for Telnet sessions.
Non-configurable field. Permits configuration through Web-
Manager.
Non-configurable field. Displays the XPort Direct+'s port for
Web-Manager configuration.
Non-configurable field. Displays the maximum baud rate of the
XPort Direct+.
Note:
the XPort Direct+ may not currently be
running at this rate.
Non-configurable field. Displays True, indicating the XPort
Direct+'s firmware is upgradeable as newer version become
available.
Non-configurable field. Displays the current IP address of the
XPort Direct+. To change the IP address, see
Address
on page 13.
Non-configurable field. Displays the number of COB partitions
supported.
Non-configurable field. Indicates whether the current IP
address on the XPort Direct+ was set manually or assigned by
DHCP.
Non-configurable field. Displays the current subnet mask of
the XPort Direct+. To change the subnet mask, see
an IP Address
on page 13.
3: Using DeviceInstaller
full version
Assigning an IP
Assigning
15
