Set the configurable pins to A = Active, I = Inactive, or X = Don't Care. Active can
mean active low or active high. If the configurable pins are all set to X (Don't Care),
then they are disabled. If both the serial sequence and the configurable pins are
disabled, the trigger is disabled.
To change the configurable pins' settings, send setup records to Port 77FE.
Message
Priority
Minimum notification
interval
Re-notification interval
Trigger 2
Refer to
Note:
Each trigger is independent of the others. Each condition within an
individual trigger must be met before the unit sends the email.
Trigger 3
Refer to
Note:
Each trigger is independent of the others. Each condition within an
individual trigger must be met before the unit sends the email.
Expert Settings (Option 5)
Note:
You can change these settings using Telnet or serial connections only,
not on the Web-Manager.
Caution:
definitely know the consequences the changes might have.
XPort Direct+ User Guide
Trigger input1 [A/I/X] (X) ?
Trigger input1 [A/I/X] (X) ?
Message () ?
Priority (L) ?
Minimum notification interval (1 s) ?
Re-notification interval (0 s) ?
The subject line of the trigger event email to the specified
recipient(s).
The priority level for the trigger even email. Enter L for normal
priority or H for high priority.
The minimum time allowed between individual triggers. If a
trigger event occurs within the minimum interval since the last
trigger, it is ignored.
Indicates the time interval at which a new email message is sent
to the recipient(s) when a single trigger event remains active.
Trigger 1
for details on completing these fields.
Trigger 1
for details on completing these fields.
Only an expert should change these parameters. You must
8: Setup Mode: Advanced Settings
56
