Server Configuration
Telnet Password
Retype Password
Advanced
ARP Cache Timeout
TCP Keepalive
Monitor Mode @ Bootup
CPU Performance Mode
HTTP Server Port
MTU Size
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Host List Configuration
The XPort Direct+ scrolls through the host list until it connects to a device listed in the
host list table. After a successful connection, the unit stops trying to connect to any
others. If this connection fails, the unit continues to scroll through the table until the
next successful connection.
The host list supports a minimum of 1 and a maximum of 12 entries. Each entry
contains an IP address and a port number.
Note:
The host list is disabled for Manual and Modem Mode. The unit does
not accept a data connection from a remote device when the hostlist option is
enabled.
To configure the XPort Direct+'s host list:
1. On the main menu, click Hostlist.
XPort Direct+ User Guide
4: Configuration Using Web Manager
Enter the password required for Telnet access.
Re-enter the password required for Telnet access.
When the unit communicates with another device on the
network, it adds an entry into its ARP table. ARP Cache
timeout defines the number of seconds (1-600) before it
refreshes this table.
TCP Keepalive time defines how many seconds the unit waits
during an inactive connection before checking its status. If the
unit does not receive a response, it drops that connection.
Enter a value between 0 and 60 seconds. 0 disables
keepalive. The default setting is 45.
Select Disable to disable entry into the monitor mode using
the 'yyy' or 'xx1' key sequence at startup. This field prevents
the unit from entering monitor mode by interpreting the stream
of characters that are received during the device server's
initialization at startup.
Select the XPort Direct+'s performance mode. Higher
performance settings require more energy. Regular is 48
Mhz; High is
88 Mhz. The default is Regular.
This option allows the configuration of the web server port
number. The valid range is 1-65535. The default port is 80.
The Maximum Transmission Unit (MTU) is the largest physical
packet size a network can transmit for TCP and UDP. Enter
between 512 and 1400 bytes. The default is 1400 bytes.
22
