Connect Mode Option
Data Echo & Modem Response
(Numeric)
Data Echo & Modem Response
(Verbose)
Modem Response Only (Numeric)
Modem Response Only (Verbose)

a) Incoming Connection

Never Accept Incoming
Accept with active
Modem Control In
Always Accept

b) Response

Character Response

c) Active Startup

No Active Startup
With Any Character
With active Modem
Control In
With a Specific Start
Character
XPort Direct+ User Guide
7 6
Rejects all external connection attempts.
Accepts external connection requests only when the Modem
Control In input is asserted. Cannot be used with Modem
Mode.
Accepts any incoming connection when a connection is not
already established. Default setting.
A single character is transmitted to the serial port when there is a
change in connection state:
C = connected, D = disconnected, N = host unreachable.
The IP address of the host connecting to the CoBos device will
be provided when you use verbose mode.
This option is overridden when the Active Start Modem Mode
or Active Start Host List is in effect. Default setting is Nothing
(quiet).
Does not attempt to initiate a connection under any
circumstance. Default setting.
Attempts to connect when any character is received from the
serial port.
Attempts to connect when the Modem Control In input changes
from not asserted to asserted.
Attempts to connect when it receives a specific start character
from the serial port. The default start character is carriage return.
7: Setup Mode: Channel Configuration
5 4 3 2
0 1 1
0 1 1
0 0 1 1
0 0 1 1
1 0
1 1
1 0
1 1
1 0
44
