6. Click the Upload Now button to transfer the file to the unit.
After the firmware has been loaded and stored, which takes approximately 8 seconds
to complete, the unit performs a power reset.

Using TFTP: Command Line Interface

To download new firmware from a computer:
1. Enter the following from a TFTP command line interface:
tftp –i <ip address> put <local filename> <destination file name>
The following examples demonstrate the TFTP command sequence to download
the .rom file and the .cob file:
tftp –i 192.168.1.111 put XPTDP_6508.rom X8
tftp –i 192.168.1.111 put gen_XPTDP_webm_1300.cob WEB1
2. In the Remote file name field, enter the current internal operational code or
WEB1 for the internal Web interface.
The TFTP destination files for XPort Direct+ is X8.
XPort Direct+ User Guide
Figure 10-1. TFTP Window
10: Firmware Upgrades
70
