Channel 1 Configuration; Serial Settings - Lantronix XPort Direct+ User Manual

2. Enter or modify the following fields:
Retry Settings
Retry Counter
Retry Timeout
Host Information
Host Address
Port
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.

Channel 1 Configuration

The Channel 1 configuration defines how the serial port responds to network and
serial communication.

Serial Settings

To configure the channel's serial
1. On the main menu, click Serial Settings (under Channel 1) to display the Serial
Settings window.
XPort Direct+ User Guide
4: Configuration Using Web Manager
Figure 4-5. Hostlist Settings
Enter the value for the number of times the XPort Direct+
should attempt to retry connecting to the host list.
Enter the duration (in seconds) the XPort Direct+ should
abandon attempting a connection to the host list.
Enter or modify the host's IP address.
Enter the target port number.
settings:
23
