Auto Negotiate
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Server Configuration
The unit's server values display when you select Server from the main menu. The
following sections describe the configurable parameters on the Server Settings page.
To configure the device server settings:
1. On the main menu, click Server.
2. Configure or modify the following fields:
XPort Direct+ User Guide
With this option, the Ethernet port auto-negotiates the speed
and duplex with the hardware endpoint to which it is
connected. This is the default.
If this option is not selected, the complete the fields that
become available:
Speed: The speed of data transmission. The default
is 100 Mbps.
Duplex: The direction of data transmission. The
default is Full.
Figure 4-4. Server Settings
4: Configuration Using Web Manager
21
