2. In the available fields, enter the following information:
Channel 1
Disable Serial Port

Port Settings

Protocol
Flow Control
Baud Rate
Data Bits
Parity
Stop Bits
XPort Direct+ User Guide
Figure 4-6. Channel Serial Settings
When selected, disables communication through the serial
port. The serial port is enabled by default.
From the drop-down menu, select the protocol type for the
selected channel.
Flow control manages data flow between devices in a network
to ensure it is processed efficiently. Too much data arriving
before a device is prepared to manage it causes lost or
retransmitted data. None is the default.
The unit and attached serial device, such as a modem, must
agree on a speed or baud rate to use for the serial connection.
Valid baud rates are 300, 600, 1200, 2400, 4800, 9600
(default), 19200, 38400, 57600, 115200, 230400, 460800, or
921600.
Indicates the number of bits in a transmitted data package.
The default is 8.
Checks for the parity bit. The default is None.
The stop bit follows the data and parity bits in serial
communication. It indicates the end of transmission. The
default is 1.
4: Configuration Using Web Manager
24
