Common Options
Telnet Com Port Cntrl
Terminal Name
Connect Response
Use Hostlist
LED
Disconnect Mode
On Mdm_Ctrl_In Drop
Hard Disconnect
Check EOT (Ctrl-D)
Inactivity Timeout
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.

Connection Settings - UDP

To configure a channel's UDP settings:
1. On the main menu, click Connection. The Connection Settings window for the
selected channel displays.
XPort Direct+ User Guide
4: Configuration Using Web Manager
This field is available for configuration only when Active
Connect is set to None. Select Enable to permit Telnet
communication to the unit. The Telnet Com Port Cntrl
feature is used in conjunction with the Com Port Redirector
(CPR) utility. (See the CPR online Help for details.)
This field is available for configuration only when Telnet Mode
is set to Enable.
Use the terminal name for the Telnet terminal type. Enter only
one name. When this option is enabled, the unit also reacts to
the end of record (EOR) and binary options, which can be
used for applications such as terminal emulation to IBM hosts.
A single character is transmitted to the serial port when there
is a change in connection state. Default setting is None.
If this option is set to True, the device server scrolls through
the host list until it connects to a device listed in the host list
table. Once it connects, the unit stops trying to connect to any
others. If this connection fails, the unit continues to scroll
through the table until it connects to another IP in the host list.
The host list is disabled for Manual Mode and for Modem
Mode. The unit will not accept a data connection from a
remote device when the host list option is enabled.
Select Blink for the status LEDs to blink upon connection or
None for no LED output.
Set to Yes for the network connection to or from the serial port
to disconnect (drop) when Modem Control In transitions from
an asserted state to not asserted state. The default setting is
No.
When set to Yes, the TCP connection closes even if the
remote site does not acknowledge the disconnect request.
Select Yes to drop the connection when Ctrl-D or Hex 04 is
detected. Both Telnet Com Port Cntrl and Check EOT
(Ctrl+ D) must be enabled for Disconnect with EOT to
function properly. Ctrl+D is only detected going from the serial
port to the network. The default setting is No.
Use this parameter to set an inactivity timeout. The unit drops
the connection if there is no activity on the serial line before
the set time expires. Enter time in the format mm:ss, where m
is the number of minutes and s is the number of seconds. To
disable the inactivity timeout, enter 00:00.
28
