2. In the available fields, enter or modify the following information:
Connect Protocol
Protocol
Connect Mode: Passive Connection
Accept Incoming
Password Required
Password
Connect Mode: Active Connection
Active Connect
Start Character
Modem Mode
Show IP Address After
Ring
Endpoint Configuration
Local Port
Auto increment for
active connect
Remote Port
Remote Host
XPort Direct+ User Guide
4: Configuration Using Web Manager
From the drop-down menu, select TCP.
Select Yes to accept incoming connections. The default is
Yes.
Determines whether a password is required for an incoming
passive connection. This field is not available when a
password is set for Telnet mode.
If Password Required was set to Yes, enter the password for
passive connections.
Select None to disable Active Connect. Otherwise, indicate
the connection type from the drop-down list:
With Any Character: Attempts to connect when any
character is received from the serial port.
With Active Mdm Ctrl In: Accepts external connection
requests only when the modem_control_in input is
asserted.
With Start Character: Attempts to connect when it
receives a specific start character from the serial port.
The default start character is carriage return.
Manual Connection: Attempts to connect when directed
by a command string received from the serial port.
Auto Start: Automatically connects to the remote IP
address and port after booting up.
If Active Connect is set to With Start Character, enter the
start character in this field.
Indicates the on-screen response type when in Modem Mode
(if Modem Mode is enabled).
Indicates whether to display the remote IP address upon
connection. The default setting is Yes.
Enter the local port number.
Select to auto-increment the local port number for new
outgoing connections. The range of auto-incremented port
numbers is 50,000 to 59,999 and loops back to the beginning
when the maximum range is reached.
Enter the remote port number.
Enter the IP address of the remote device.
