7: Setup Mode: Channel Configuration

This chapter explains how to configure the serial port.
Notes:
Current values display in parenthesis.
You must enter some values in hexadecimal notation. (See
Hexadecimal Conversions.)

Channel 1 (Option 1)

Select Channel 1 (option 1) from the Change Setup menu to define how the serial
port responds to network and serial communications. The following sections describe
the configurable parameters within the Channel configuration menu.
XPort Direct+ User Guide
Figure 7-1. Serial Port Parameters
A: Binary to
40
