Show IP addr after 'RING'

Disable or enable the Micro125's ability to show the IP address after RING in Modem Mode.
The default is Y (Yes), to show the IP address.

Auto Increment Source Port

Y (Yes) auto increment the source port. The Micro125 increments the port number used with
each new connection.

Remote IP Address

This is the destination IP address used with an outgoing connection.
Note: This option does not display when Hostlist is enabled from the ConnectMode prompt
(see Connect Mode

Remote Port

You must set the remote TCP port number for the unit to make outgoing connections. This
parameter defines the port number on the target host to which a connection is attempted.
To connect an ASCII terminal to a host using the unit for login purposes, use the remote port
number 23 (Internet standard port number for Telnet services).
Note: This option does not display when Hostlist is enabled from the ConnectMode prompt
(see Connect Mode

DisConnMode

This setting determines the conditions under which the unit will cause a network connection
to terminate.
Notes:

In DisConnMode (Disconnect Mode), Modem Control In drop either drops the connection
or is ignored.

All bit positions in the table that are blank represent "don't care" bits, for that particular
option, which can be set to either a 0 or 1 value.
Micro125 User Guide
Show IP addr after 'RING' (Y) ?
Auto increment source port (N) ? _
Remote IP Address : (000) (000) (000) (000)_
on page 44 for more information).
Remote Port (00) ? _
on page 44 for more information).
DisConnMode (00) ? _
8: Setup Mode: Channel Configuration
51
