2. Click the Assign IP icon
3. If prompted, enter the hardware address (on the product label) and click Next.
4. Select Assign a specific IP address and click Next.
5. Enter the IP address. The Subnet mask displays automatically based on the IP
address; if desired, you may change it. On a local network, you can leave the
Default gateway blank (all zeros). Click Next.
6. Click the Assign button and wait several seconds until a confirmation message
displays. Click Finish.
7. Select the device from the main window list and select Ping from the Tools
menu. The Ping Device dialog box shows the IP address of the selected unit.
8. From the Tools menu, click the Ping button. The results display in the Status
window. Click the Clear Status button to clear the window so you can ping the
device again.
Note:
properly attached to the network and that the IP address assigned is
valid for the particular network segment you are working with. If you are
not sure, check with your systems administrator.
9. Click the Close button to close the dialog box and return to the main window.

Accessing the XPort Direct+ Using DeviceInstaller

1. Click Start Programs
2. Click the XPort folder. The list of available Lantronix XPort Direct+ devices
displays.
3. Expand the list of devices by clicking the + symbol next to the XPort Direct+ icon.
Select the XPort Direct+ unit by clicking on its IP address to view its
configuration.

Viewing the Current Configuration

DeviceInstaller provides a view of the unit's configuration.
To view the unit's current settings:
1. Follow the instructions above to locate the XPort Direct+.
2. In the right pane, click the Device Details tab. The current XPort Direct+
configuration displays:
Name
XPort Direct+ User Guide
.
If you do not receive "Reply" messages, make sure the unit is
Lantronix DeviceInstaller DeviceInstaller.
Configurable field. A name that identifies the XPort Direct+.
Double-click the field, type in the value, and press Enter to
complete. This name is not visible on other PCs or laptops
using DeviceInstaller.
3: Using DeviceInstaller
14
