Send The Escape Sequence (+++) In Modem Mode; Show Ip Addr After 'Ring; Auto Increment Source Port - Lantronix xPico User Manual

Modem Mode
Command
ATD0.0.0.0
ATD or ATDT
ATDx.x.x.x
ATH
ATS0=n
ATEn
ATVn
Note: The unit recognizes these AT commands as single commands such as ATE0
or ATV1; it does not recognize compound commands such as ATE0V.

Send the Escape Sequence (+++) in Modem Mode

Disable or enable the xPico's ability to send the escape sequence. The default is Y
(Yes) (send the escape sequence).

Show IP addr after 'RING'

Disable or enable the xPico's ability to show the IP address after RING in Modem
Mode. The default is Y (Yes), to show the IP address.

Auto Increment Source Port

xPico User Guide
Function
Forces the unit into Monitor Mode if a remote IP address and port
number are defined within the unit.
Forces the unit into Monitor Mode if a remote IP address and port
number are not defined within the unit.
Makes a connection to an IP address (x.x.x.x) and the remote port
number defined within the unit.
Hangs up the connection (Entered as +++ATH ).
Enables or disables connections from the network going to the serial
port.
n=0 disables the ability to make a connection from the network to the
serial port.
n=1-9 enables the ability to make a connection from the network to
the serial port.
n>1-9 is invalid.
Enables or disables character echo and responses.
n=0 disables character echo and responses.
n=1 enables character echo and responses.
Enables numeric response or full verbose.
n=0 enables numeric response.
n=1 enables full verbose.
Send '+++' in Modem Mode (Y) ? _
Show IP addr after 'RING'
Auto increment source port (N) ? _
7: Setup Mode: Channel Configuration
(Y)
49
