This option applies to XPort Direct+ and later units only. It allows you to increase the
CPU performance required to use the higher baud rates on the serial interface (460
Kbps and 920 Kbps). The standard CPU performance mode supports up to 230400
Kbps.
Notes:
If a baud rate of 460 Kbps or 920 Kbps is set and the high performance mode is
disabled, the operation of the serial channel would be out of the specified error
tolerance, thereby leading to inconsistent speed settings on the two ends of the
serial channel.
Increasing CPU clock speed consumes more power and generates more heat.
This reduces the maximum operating temperature specification. See the
appropriate product brief for details.

Disable Monitor Mode at bootup

This option allows you to disable all entries into Monitor Mode during startup, except
for the 'xxx' sequence. This prevents entry using yyy, zzz, xx1, and yy1 key
sequences (only during the bootup sequence). The default for Monitor Mode at
bootup is N (No). (See
Disable Monitor Mode @ bootup (N) ? _

HTTP Port Number

This option allows the configuration of the web server port number. The valid range is
1-65535. The default HTTP port number is 80.
HTTP Port Number : (80) ? _

SMTP Port Number

This option allows the configuration of the email port number. The valid range is
1-65535. The default SMTP port number is 25.
SMTP Port Number : (25) ? _
Note: When configuring the HTTP or SMTP port number, take note of the 'reserved'
port numbers on page 42.

MTU Size

The Maximum Transmission Unit (MTU) is the largest physical packet size a network
can transmit for TCP and UDP. Enter between 512 and 1400 bytes. The default is
1400 bytes.
MTU Size: (1400) ? _

Enable alternate MAC

XPort Direct+ User Guide
11:Monitor Mode.)
8: Setup Mode: Advanced Settings
58
